E-9 STARTING CLUTCH

E-9 STARTING CLUTCH
Например: 22350-HP7-A00
1
22350-HP7-A00
LATE COMP., DRIVE
2
22451-HP5-601
SPRING, CLUTCH
3
22500-HP7-A00
OUTER COMP., CLUTCH
4
22535-HP7-305
WEIGHT SET, CLUTCH
5
22714-HP5-600
SPRING, CONED DISK
6
23120-HP7-A00
GEAR COMP., DRIVE (25T)
7
90235-HM7-000
Nut (20 mm)
8
90406-HP5-600
WASHER, 64X122X1.0
9
90407-HP5-600
WASHER, 64X105X2
10
90457-HN2-000
WASHER, THRUST, 29X40X2
11
90459-KB4-670
Rondelle (20 mm)
535 ₽/шт
12
90605-166-720
CIRCLIP, 7MM
204 ₽/шт
13
91101-HN2-003
CLUTCH, ONE WAY
