E-16 CRANK SHAFT/PISTON

E-16 CRANK SHAFT/PISTON
Например: 13000-HP7-A00
1
13000-HP7-A00
Vilebrequin
2
13010-HP5-600
Kir segment (STD)
2
13011-HP5-600
Kir segment (0,25 mm)
2
13012-HP5-600
RING SET, PISTON (0.50)
3
13102-HP5-600
iston (0.25)
3
13103-HP5-600
ISTON (0.50)
3
13101-HP5-600
iston (STD)
4
13111-HP5-600
iston pin
5
13112-MAT-000
CLIP, PISTON PIN, 19MM
165 ₽/шт
6
13420-HP5-600
SHAFT COMP., BALANCER (32
7
90741-ZE2-000
KEY, SPECIAL WOODRUFF, 25
8
91001-HM7-008
Roulement
9
91002-HP5-601
BEARING, RADIAL BALL, 40X
10
96100-620-3300
ПОДШИПНИК ВЫЖИМНОЙ
678 ₽/шт
