F-10 MAIN TRANSMISSION DRIVE GEAR / REAR AXLE HALF AXLE

F-10 MAIN TRANSMISSION DRIVE GEAR / REAR AXLE HALF AXLE
Например: 12361-035-000
1
12361-035-000
Vis de vidange d'huile
2
41300-HA0-680
CASE ASSYFINAL G
3
41301-HA0-680
CASE COMP.FINAL
4
41310-HA0-300
GEAR SETFINAL
5
41321-HA0-680
COVERFINAL GEAR
6
41411-HA0-000
JOINT, PINION
7
41436-MB0-310
PIN, RING GEAR STOPPER
1 662 ₽/шт
8
41438-MB0-310
SHIM B, STOPPER PIN (0.15
425 ₽/шт
9
41457-HA0-000
SHIM GPINIO.GEAR
10
41548-HA0-000
SPACER I, RING GEAR (2.30
11
42311-HA0-680
XLEREAR WHEEL (Rear)
12
90109-371-000
BOLT, SEALING, 8MM
385 ₽/шт
13
90133-MB0-000
Vis
613 ₽/шт
14
90134-HA0-000
Vis
566 ₽/шт
15
90244-HA0-000
Nut (60 mm)
2 455 ₽/шт
16
90381-HA0-000
Nut (16 mm)
579 ₽/шт
17
90471-580-000
Gasket (8 mm)
157 ₽/шт
18
91061-HA0-004
Needle bearing (14x22x16)
19
91063-HC4-771
Roulement
20
91251-HC5-005
Joint
1 242 ₽/шт
21
91252-HA0-004
Joint
760 ₽/шт
22
91253-HA0-004
Joint
23
91302-001-020
O-Ring
381 ₽/шт
24
95001-359-9940S
TUBE
25
95002-02070
Collier
47 ₽/шт
26
96100-600-7300
Bearing (6007)
1 195 ₽/шт
