E-12 CAMSHAFT / PISTON

E-12 CAMSHAFT / PISTON
Например: 13000-HA0-770
1
13000-HA0-770
Vilebrequin
2
13051-HC4-306
RING SETPISTON (
3
13105-HA0-305
Piston (std. 1.00)
4
13111-KG0-000
Piston pin
5
13201-HA0-300
RODCONNECTING
6
13202-HA0-300
PLATECONNECTING
1 163 ₽/шт
7
13213-428-300
BEARINGCON ROD
8
13311-HA0-680
FŐTENGELY JOBB
9
13321-HA0-300
FŐTENGELY BAL
10
13331-357-000
KEY, SPECIAL WOODRUFF, 25
393 ₽/шт
11
13381-HA0-770
PIN COMP.CRANK
12
13410-HA0-300
GEARBAL DRIVE
9 950 ₽/шт
13
13420-HA0-000
SHAFT COMPBALANC
14
15130-HA0-300
GEAROIL PUMP DRI
1 931 ₽/шт
16
91001-KE5-018
Roulement
17
91010-HC4-004
Roulement
18
91003-HA7-672
Roulement
1 101 ₽/шт
19
91009-HA0-004
Roulement
1 571 ₽/шт
20
94601-19000
CLIP, PISTON PIN, 19MM
47 ₽/шт
