Главная Каталог товаров Polaris EPC 1996 Polaris ATV Polaris 1996 SPORTSMAN 4X4 (W968040) Polaris 1996 ATV COOLING SYSTEM Sportsman 4x4 W968040 (4935943594A011) | COOLING SYSTEM Sportsman 4x4 W968040 (4935943594A011)

COOLING SYSTEM Sportsman 4x4 W968040 (4935943594A011) | COOLING SYSTEM Sportsman 4x4 W968040 (4935943594A011)

COOLING SYSTEM Sportsman 4x4 W968040 (4935943594A011) | COOLING SYSTEM Sportsman 4x4 W968040 (4935943594A011)

Например: 7517221

1

7517221

Vis

2

7558201

WASHER FLAT

3

4170009

MOTOR FAN LIQ.COOLED

4

5333073

SPACER, FAN BRKT.

5

7547004

NUT

6

5411173

HOSE LOWER ENGINE

7

7542122

NUT-NYLOK

8

7558301

WASHER FLAT

9

3110032

MOUNT RUBBER

10

5020572

SPACER MOUNT

11

7080614

CLAMP HOSE

12

5410570

HOSE ENG UPPER

13

2511270

CAP PRESSURE (13 LB)

14

2460515

HARNESS FAN/THERM.SWITCH

15

4110189

SWITCH ASM THERMAL FAN L/C

16

7052116

FITTING HEX BUSH

17

1240006

RADIATOR

18

7552605

Rondelle

19

7512113

Vis

20

7512193

BOLT CARRIAGE

21

5431610

COVER RADIATOR W/MESH

22

5222547-067

GUARD,LOW.RADIATOR

23

7670090

CLIP PLASTIC DART NYLON

24

5410607

O RING

25

5431188

SHIELD LH RADIATOR

25

5431189

SHIELD RH RADIATOR

26

5410584

BUSHING-MOUNT LOWER RADIATOR

27

3083952

NUT

28

7558301

WASHER FLAT

29

5240822

BLADE, FAN

30

3083950

BUSHING

31

7512252

SCREW(10)

32

5224741-067

BRKT COOL.FAN BLK

33

5224741-067

BRKT COOL.FAN BLK

34

5333457

Entretoise

35

7542154

Nut

36

5432294

SPACER,FAN BRKT.

37

4170011

MOTOR,FAN,LQ,W/CONNECTOR

37

4170009

MOTOR FAN LIQ.COOLED
