Главная Каталог товаров SUZUKI EPC 1099 cm³ < SUZUKI GV 1400 Cavalcade SUZUKI GV1400GD J Cavalcade SUZUKI 95 - CB RADIO KIT OPTIONAL

95 - CB RADIO KIT OPTIONAL

95 - CB RADIO KIT OPTIONAL

Например: 38800-24824

1

38800-24824

Cb radio kit

2

38800-24A00

.adapter & switch, cb radio

3

01500-0516B

Болт

1 060 ₽/шт

4

01500-0510B

Болт

85 ₽/шт

5

08321-0105A

Пластина замка

81 ₽/шт

6

08321-0104A

Пластина замка

82 ₽/шт

7

08310-0004A

Гайка

1 090 ₽/шт

8

09309-20003

.grommet

9

38890-24A00

.switch assy, back up

10

09407-18402

Струбцина (L:165)

211 ₽/шт

11

39280-24A02

.indicator assy,cb ch

12

03242-0416B

Болт

289 ₽/шт

13

03541-04308

.screw

14

09180-05049

15

09160-04026

Шайба

141 ₽/шт

16

37870-24A10

.switch assy,cb chan

17

37875-24A10

..screw,tapping (4x50)

18

95867-24A00

.grommet, no.1

19

95867-24A10

.grommet, no.2

20

33552-24A10

.filter, motor noise

21

02112-0408B

Болт

940 ₽/шт

22

08322-0104B

Шайба

81 ₽/шт

23

33551-24A11

.condenser, cb unit

24

02112-0610B

Винт

81 ₽/шт

25

08322-0106A

Шайба

81 ₽/шт

26

36851-24A10

.wire body earth

27

39260-24A01

ntenna, cb

28

95860-24A81

ntenna holder cav

29

37800-24841

Co-rider remo-con kit

29

37800-24830

Co-rider remo-con kit

30

37870-24A31

.switch channel selec

30

37870-24A20

.switch assy,cb chan

31

36854-24A20

.wire,cb channel sele

32

45480-24A80

.panel tuner assy

32

45480-24A90

.panel,tuner assy,no.

33

45426-24A90

.grommet, wire

34

45426-24A70

.grommet wire

35

45426-24A80

.grommet wire
