11 - CARBURETOR FOR CALIFORNIA

11 - CARBURETOR FOR CALIFORNIA

Например: 13201-24A50

1

13201-24A50

Carb assy, front, lh

2

13202-24A50

Carb assy, front, rh

3

13203-24A50

Carb assy, rear, lh

4

13204-24A50

Carb assy, rear, rh

5

13502-38A00

COVER,DIAPHRAGM

2 502 ₽/шт

6

13503-05A10

Пружина

864 ₽/шт

7

13389-37400

PLATE

368 ₽/шт

8

13387-44030

RING

323 ₽/шт

9

13394-31210

CLIP,NEEDLE

238 ₽/шт

10

13382-44030

Шайба

4 110 ₽/шт

11

13388-44030

Пружина

1 143 ₽/шт

12

13500-05A10

DIAPHRAGM,CARBURETOR

15 647 ₽/шт

13

13383-24A10

.needle,jet

14

09494-00505

.jet needle

15

13605-05A10

Болт

559 ₽/шт

16

13382-03110

Шайба

178 ₽/шт

17

02112-0510B

Болт

85 ₽/шт

18

13251-38A00

Уплотнитель поплавковой камеры

1 211 ₽/шт

19

13385-05A11

HOLDER,MAIN JET

1 024 ₽/шт

20

09491-21023

JET,MAIN(105)

657 ₽/шт

21

13250-05A10

Поплавок

2 424 ₽/шт

22

13254-20010

Поплавок

178 ₽/шт

23

13370-24A00

.valve,needle

24

13374-35C00

КОЛЬЦО УПЛОТНИТЕЛЬНОЕ

275 ₽/шт

25

13376-19F00

Фильтр-сеточка

581 ₽/шт

26

09492-25007

Жиклерпроводник #

888 ₽/шт

27

09492-67001

.jet, air (67.5)

28

13411-05A10

.plunger

29

13417-05A10

.spring

30

13278-47091

O Ring

210 ₽/шт

31

13418-05A10

Держатель

864 ₽/шт

32

13601-04148

Болт

172 ₽/шт

33

13603-05A20

.screw

34

13692-05A10

.clip

35

13551-05A00

.valve, throttle

36

13604-44080

Болт

235 ₽/шт

37

02112-0306B

Болт

940 ₽/шт

38

13484-38A10

COVER

1 150 ₽/шт

39

13480-05A10

.diaphragm

40

13481-45C10

Пружина

375 ₽/шт

41

02112-0412A

Болт

85 ₽/шт

42

13627-24A00

.bracket

43

13605-05A20

.screw

44

13271-05A10

.spring

45

13550-07A10

.shaft assy

46

13268-96111

Пружина

179 ₽/шт

47

13550-07A20

.shaft assy

48

13573-05A10

.spring

49

13447-05A10

.plate

50

13550-07A30

.shaft assy

51

13573-24A10

.spring

52

13553-05A10

.lever

53

13553-05A20

.lever

54

13563-47070

.pin

55

13553-05A30

.lever

56

08310-00087

Гайка 8MM

81 ₽/шт

57

13606-47070

WASHER,THROTTLE SHAFT

58

13557-05A20

.ring

59

13573-24A00

.spring

60

13550-07A40

.shaft assy

61

13573-05A40

.spring

62

13617-44080

E RING

231 ₽/шт

63

13557-47070

GASKET,THROTTLE SHAFT

301 ₽/шт

64

13556-05A11

Seal,throttle Shaft

238 ₽/шт

65

08310-00047

Гайка

81 ₽/шт

66

13602-05A10

Болт

238 ₽/шт

67

09404-06039

Clamp(L:65)

194 ₽/шт

68

13692-24A00

Clamp

69

09352-50005-600

ШЛАНГ

436 ₽/шт

70

13683-24A50

.hose (5x9x270)

71

09401-08413

Collier

72

13671-05A40

ХОМУТ

170 ₽/шт
