90 - SIDE BAG GV1400GDG/GTG

90 - SIDE BAG GV1400GDG/GTG

Например: 95400-24A01-7UM

1

95400-24A01-7UM

Side bag assy, rh

1

95400-24A01-7UN

Side bag assy,rh

1

95400-24A11-12S

ide bar assy,rh (maroon)

1

95400-24A11-24K

Side bar assy,rh (charcoal)

2

68260-24A00-7UP

.tape set,side bag,rh

2

68260-24A00-7UR

.tape set,side bag,rh

2

68260-24A10-78V

.tape set,side bag rh

2

68260-24A10-7US

.tape set,side bag rh

3

93316-24A02

.lock plate,trunk lid

4

93316-24A13

.lock plate,sidebag l

5

95440-24A00-24G

.lid,side bag,r (gold)

5

95440-24A00-24H

.lid side bag (brown)

5

95440-24A00-12S

.lid,side bag,r (maroon)

5

95440-24A00-24K

.lid side bag rh (charcoal)

6

95422-24A01

..seal,side bag

7

95446-24A02

SEAL

8

95516-24A00

..holder lid lock

9

03511-03125

..screw,holder

10

95423-24A10

..plate lid lock

11

95447-24A00

..lever,pocket opener

12

95424-24A00

Plate, lid lock

13

02142-0406A

Болт

85 ₽/шт

14

95443-24A00

Hinge,side bag

15

02142-0406A

Болт

85 ₽/шт

16

02142-0412A

Болт

740 ₽/шт

17

95448-24A00

Lid

18

95500-24A01-7UM

Side bag assy,lh

18

95500-24A01-7UN

Side bag assy,lh

18

95500-24A11-12S

ide bag assy,lh (maroon)

18

95500-24A11-24K

Side bag assy,lh (charcoal)

19

68290-24A00-7UP

.tape set,side bag,lh

19

68290-24A10-78V

.tape set,side bag lh

19

68290-24A10-7US

.tape set,side bag lh

19

68290-24A00-7UR

.tape set,side bag,lh

20

93316-24A02

.lock plate,trunk lid

21

93316-24A13

.lock plate,sidebag l

22

95540-24A00-24G

.lid,side bag,l (gold)

22

95540-24A00-12S

.lid (maroon)

22

95540-24A00-24K

.lid,side bag,l (charcoal)

22

95540-24A00-24H

.lid,side bag,l (brownj)

23

95422-24A01

..seal,side bag

24

95446-24A02

SEAL

25

95516-24A00

..holder lid lock

26

03511-03125

..screw,holder

27

95423-24A10

..plate lid lock

28

95447-24A00

..lever,pocket opener

29

95424-24A00

Plate, lid lock

30

02142-0406A

Болт

85 ₽/шт

31

95443-24A00

Hinge,side bag

32

02142-0406A

Болт

85 ₽/шт

33

02142-0412A

Болт

740 ₽/шт

34

95448-24A00

Lid

35

93124-24A00

Set plate lock side

36

93300-24820

Lock set,side bag

37

02142-0508A

SCREW

85 ₽/шт

38

68261-24A10

Emblem,side bag,r

38

68261-24A00

Emblem, side bag l

39

01500-06307

Болт

85 ₽/шт

40

09160-06136

Шайба

102 ₽/шт

41

09180-06055

Entretoise

42

09320-09017

CUSHION

2 540 ₽/шт

43

95416-24A00

Seat,side bag bottom, rh

44

95417-24A00

Seat,side bag bottom, lh

45

09800-00293

Tool assy

46

96200-41330

Gauge assy,air

46

96200-24A00

Gauge assy air press

47

95450-24A01

Bag, side luggage

48

09462-00040

Лента

2 040 ₽/шт

49

01204-06307

BOLT

980 ₽/шт

50

09160-06136

Шайба

102 ₽/шт

51

09180-06055

Entretoise

52

09320-09017

CUSHION

2 540 ₽/шт

53

09160-06121

Шайба

1 520 ₽/шт

54

08319-31067

Гайка

153 ₽/шт

55

09250-08013

CAP(OD:12)

1 410 ₽/шт

56

68613-24A02

utocollant (WARNING)

57

93314-24A01

Packing seat,sidebag
