23 - PROPELLER SHAFT-FINAL DRIVE GEAR

23 - PROPELLER SHAFT-FINAL DRIVE GEAR

Например: 27300-24833

1

27300-24833

Gear/case set,final

1

27311-24A03

GEAR,FINAL DRIVE BEVEL

16 305 ₽/шт

2

09262-28023

ПОДШИПНИК

5 411 ₽/шт

3

27312-24A02

STOPPER,FINAL DRIVE BEARING

3 734 ₽/шт

4

27313-24A00

.plate,bearing stoppe

5

27313-24A10

.plate,bearing stoppr

6

09280-67004

O RING(D:2.1,ID:66.2)

226 ₽/шт

7

09160-54001

Шайба

5 040 ₽/шт

8

27445-24A01-060

.shim,final drive gr (t:0.60)

8

27445-24810

SHIM SET,FINAL DRIVE GEAR

1 412 ₽/шт

9

09283-47002

САЛЬНИК

1 082 ₽/шт

10

27172-24A00

COUPLING,FINAL DRIVE GEAR

7 671 ₽/шт

11

09160-16029

Шайба

3 170 ₽/шт

12

09159-16003

ГАЙКА

178 ₽/шт

13

01421-1025B

Болт

1 840 ₽/шт

14

09263-20062

BEARING(20X34X18)

2 020 ₽/шт

15

09262-70001

Подшипник

8 758 ₽/шт

16

27327-45810

Shim set, driven gear bearing

17

09289-70001

Сальник

3 957 ₽/шт

18

09263-35004

Подшипник

6 057 ₽/шт

19

27326-45811

Shim set,fdg.

19

27326-45100-140

.shim final drvn gear (t:1.40)

19

27326-45104

.thrust shim (t:1.35)

19

27326-45100-150

.shim final drvn gear (t:1.50)

19

27326-45100-145

.shim final drvn gear (t:1.45)

20

27329-45100

Holder,bearing

21

02112-06127

Болт

81 ₽/шт

21

02122-06127

Болт

85 ₽/шт

22

09283-30028

SEAL,OIL(30X42X7)

563 ₽/шт

23

27450-24A03

.case,final gear

24

09108-10077

.bolt, stud

25

27460-24A01

.case,final gear bear

26

09280-10016

КОЛЬЦО УПЛОТНИТЕЛЬНОЕ РЕЗИНА

162 ₽/шт

27

27481-24A00

Vis

28

09169-12003

.washer

29

09140-12039

Гайка

187 ₽/шт

30

01550-08307

БОЛТ

114 ₽/шт

31

09247-14026

Пробка редуктора сливная

289 ₽/шт

32

09168-14004

Прокладка

129 ₽/шт

33

09247-14036

Заглушка масляного дренажа

210 ₽/шт

34

09168-14004

Прокладка

129 ₽/шт

35

09440-30008

Пружина

1 840 ₽/шт

36

09381-40003

Стопорное кольцо (пружинное)

2 820 ₽/шт

37

09283-30026

SEAL,OIL(30X40.5X5.5)

1 696 ₽/шт

38

08321-0110B

Пружинная шайба

85 ₽/шт

39

09159-10027

Гайка

211 ₽/шт

40

27100-24A06

Shaft,propeller

41

27171-45101

Ring prop shaft cup
