7 - CRANKSHAFT

7 - CRANKSHAFT

Например: 12220-24A10

1

12220-24A10

Crankshaft

2

12229-05A00-0D0

Brg c shaft r l (yellow)

2

12229-05A00-0B0

rg c shaft rl (black)

2

12229-05A00-0A0

Brg c shaft r l (green)

2

12229-05A00-0C0

Brg c shaft r l (brown)

3

12229-05A10-0B0

rg c shaft mdl (black)

3

12229-05A10-0A0

Brg c shaft mdl (green)

3

12229-05A10-0D0

Brg c shaft mdl (yellow)

3

12229-05A10-0C0

Brg c shaft mdl (brown)

4

12228-05A00-0D0

Brg crank thrust r

5

12228-05A00-0C0

Brg crank thrust l (blue)

5

12228-05A00-0D0

Brg crank thrust l (green)

5

12228-05A00-0E0

Brg crank thrust l (yellow)

5

12228-05A00-0F0

Brg crank thrust l (white)

5

12228-05A00-0A0

Brg crank thrust l (red)

5

12228-05A00-0B0

rg crank thrust l (black)

6

12160-24A02

Connrod assy

7

09159-09001

Гайка

179 ₽/шт

8

12164-24A00-0A0

Bearing,crank pin (green)

8

12164-24A00-0B0

earing,crank pin (black)

8

12164-30E00-0C0

BEARING,CRANK PIN

2 072 ₽/шт

8

12164-24A00-0D0

Bearing,crank pin (yellow)

9

21111-05A02

Gear,primary drive

10

12744-05A00

Sprkt,ch drive idler

11

17531-24A00

Sprocket,wtr pump,dr

12

09103-10112

BOLT(10X24)

211 ₽/шт

13

12111-24A05

Piston

13

12111-24A05-100

Piston (os:1.0)

13

12111-24A05-050

Piston (os:0.5)

14

12140-24A00

Ring set,piston

14

12140-24A00-050

Ring set,piston (os:0.5)

14

12140-24A00-100

Ring set,piston (os:1.0)

15

12151-24A00

Палец поршня

1 615 ₽/шт

16

09381-20004

КОЛЬЦО СТОПОРНОЕ

162 ₽/шт
