60 - REAR SHOCK ABSORBER (MODEL E/G/H/J)

60 - REAR SHOCK ABSORBER (MODEL E/G/H/J)

Например: 62100-13A40-19F

1

62100-13A40-19F

bsorber assy,rear shock (blue)

2

62226-14520

Seal,dust

3

62684-14520

Collar

4

09103-10040

BOLT(10X54)

3 400 ₽/шт

5

08319-31107

Гайка

210 ₽/шт

6

62331-13A00

CUSHION,RESERVOIR TANK UPR

481 ₽/шт

7

62411-13A00

Bracket,lower

8

62423-13A00

Cushion,lower

9

01500-0612B

Болт

1 210 ₽/шт

10

08321-0106A

Шайба

81 ₽/шт

11

08322-0106A

Шайба

81 ₽/шт

12

09402-69511

CLAMP

6 020 ₽/шт

13

09407-14407

ЗАЖИМ

221 ₽/шт
