Главная Каталог товаров SUZUKI EPC 125 cm³ - 349 cm³ SUZUKI TS 250 SUZUKI TS250X J SUZUKI 6 - CRANKSHAFT

6 - CRANKSHAFT

6 - CRANKSHAFT

Например: 12110-13A15-0F0

1

12110-13A15-0F0

Piston (70mm)

1

12103-13820-050

Piston kit 70.5

1

12103-13820-100

Piston set 1.00

2

12140-19A10

Ring set, piston

2

12140-19A10-050

Ring set,piston (0s:0.5)

2

12140-19A10-100

Ring set,piston (0s:1.0)

3

12151-13A00-0A0

Палец поршневой

1 337 ₽/шт

4

09381-18002

Стопор

119 ₽/шт

5

09263-18021

BEARING(18X23X24)

1 962 ₽/шт

6

09169-18005

Шайба

3 280 ₽/шт

7

12200-13A10

Vilebrequin

8

12161-13A10

Connecting rod

15

12661-13A10

Gear,crank balancer drive

16

09280-28005

O RING(D:2.4,ID:27.7)

1 410 ₽/шт

17

09262-30066

Ball bearing 30

18

09262-32006

Подшипник

5 279 ₽/шт

19

09289-36005

Seal ,oil

20

09283-25078

Oil seal

21

21111-13A01

Gear,primary drive

22

08341-31069

Ключ

2 820 ₽/шт

23

17451-13A01

DRIVE GEAR

24

09164-14011

Шайба

1 250 ₽/шт

25

09159-14012

Nut

26

09181-30164

Шайба

1 990 ₽/шт

26

09181-30165

SHIM(30X40X0.95)

1 990 ₽/шт

26

09181-30045

SHIM 1.00

26

09181-30046

SHIM30X40X105

2 150 ₽/шт

26

09181-30047

SHIM(30X40X1.1)

2 150 ₽/шт

26

09181-30048

SHIM(30X40X1.15)

2 150 ₽/шт

26

09181-30049

SHIM 1.2

26

09181-30042

SHIM(30X40X0.75)

2 110 ₽/шт

26

09181-30041

SHIM(30X40X0.8)

194 ₽/шт

26

09181-30039

SHIM(30X40X0.65)

2 110 ₽/шт

26

09181-30038

SHIM(30X40X0.65)

2 110 ₽/шт

26

09181-30037

SHIM(30X40X0.6)

2 110 ₽/шт

26

09181-30050

SHIM 1.25

26

09181-30040

SHIM(30X40X0.75)

2 110 ₽/шт
