15 - CLUTCH

15 - CLUTCH

Например: 21200-13A04

1

21200-13A04

PRIM DR GEAR 65/18

2

21251-14601

Entretoise

3

09263-25044

Roller bearing

4

21411-13A01

Hub,clutch slee

5

09160-20054

Thrust washer

6

09167-20006

ШАЙБА

136 ₽/шт

7

09140-20001

Гайка

179 ₽/шт

8

21441-13A01

ДИСК ФРИКЦИОННЫЙ

1 244 ₽/шт

9

21451-19A00

Диск сцепления

901 ₽/шт

10

21451-36200

PLATE

697 ₽/шт

11

21471-36200

SEAT,WAVE WASHER

4 590 ₽/шт

12

21481-39301

Кольцо стопорное

238 ₽/шт

13

09164-98001

Шайба

1 697 ₽/шт

14

21462-32C50

Disk clutch

15

09440-15020

Spring

16

09100-05002

BOLT(5X16)

114 ₽/шт

17

09160-05043

Шайба

102 ₽/шт

18

23165-13A00

Rack,clutch rel

19

23261-13A01

PINION,CLUTCH RELEASE

2 522 ₽/шт

20

09160-12086

WASHER(12.5X17X1)

1 090 ₽/шт

21

09263-10002

ПОДШИПНИК

697 ₽/шт

22

09285-10004

САЛЬНИК

210 ₽/шт

23

23271-14103

ARM,CLUTCH RELEASE

2 502 ₽/шт

24

01500-06167

БОЛТ

85 ₽/шт
