Main Frame Assembly

Main Frame Assembly

Например: T2071681

1

T2071681

Frame Assembly, US

1 шт. в узле

1

T2071682

Frame Assembly, BR

1 шт. в узле

1

T2071683

Frame Assembly, TH

1 шт. в узле

1

T2071707

Frame Assembly, ROW

1 шт. в узле

1

T2072667

Frame Assembly, CN

1 шт. в узле

1

T2071667

Frame Assembly, CA

1 шт. в узле

1

T2071668

Frame Assembly, AU

1 шт. в узле

2

T2073464

Cradle Assembly, LH, ED & Powd

1 шт. в узле

3

T2073472

Cradle Assembly, RH, ED & Powder

1 шт. в узле

4

T3151024

Bolt, HHF, M12 x 75, 10,9, Slv

2 шт. в узле

5

T3151021

Bolt, HHF, M12 x 55, 10.9, Slv

2 шт. в узле

6

T3501795

Washer, M12, OD26, Hardened, S

3 шт. в узле

7

T2075055

Bracket, M10

4 шт. в узле

8

T3203206

Screw, Cap/Hd, M10 x 35, Slv

8 шт. в узле

9

T3350219

hreaded Insert

7 шт. в узле

10

T2076401

Cradle Stiffener

1 шт. в узле

11

T2071709

Bracket, M8

1 шт. в узле

12

T3205156

Bolt, HHF, Lghtd, M8 x 18, Slv

4 шт. в узле

13

T3334675

Bolt, HHF, M12 x 240, Slv

1 шт. в узле

14

T3334662

Screw, Torx, M12 x 265

1 шт. в узле

15

T3350234

Locknut, Flgd, M12 x 1.25

6 шт. в узле

16

T2072119

Spacer, 13 x 24 x 29

1 шт. в узле

17

T2072118

Spacer, 13 x 28 x 15

1 шт. в узле

18

T2400854

ank Mount Bush

2 шт. в узле

19

T2072929

Pad, Protection, Fuel Tank

1 шт. в узле

20

T2071708

Bung

1 шт. в узле

21

T2071980

Adjuster, Frame, M12

3 шт. в узле

22

T2076548

Adjuster, Threaded

2 шт. в узле

23

T2051010

Swingarm Pivot Adjuster

1 шт. в узле
