11 - TRANSMISSION (MODEL Z)

11 - TRANSMISSION (MODEL Z)
Например: 24120-14220
1
24120-14220
Countershaft (nt:14)
2
24221-14220
Gear, 2nd drive (nt:18)
3
24230-14220
Gear, 3rd drive (nt:19)
4
24240-14220
Gear, 4th drive (nt:22)
5
08211-25301
Шайба
1 840 ₽/шт
6
09380-25003
КЛИПС
291 ₽/шт
7
09262-22025
Подшипник
3 715 ₽/шт
8
09262-20106
Подшипник B1 20X42X12
1 190 ₽/шт
9
08211-20283
WASHER
1 370 ₽/шт
10
24741-14210
Holder, bearing
11
02112-06127
Болт
81 ₽/шт
11
02122-06127
Болт
85 ₽/шт
12
24130-14220
Driveshaft (4th, nt:21)
13
24311-14220
Gear, 1st driven (nt:28)
14
24320-14220
Gear, 2nd driven (nt:28)
15
24331-14220
Gear, 3rd driven (nt:23)
16
09181-20195
Шайба
194 ₽/шт
17
08211-20363
WASHER
194 ₽/шт
18
09167-28004
Washer
19
09380-28004
Circlip
20
09263-20018
Roulement
21
09264-20002
Bearing, rh
22
09262-28004
BEARING(28X58X16)
3 011 ₽/шт
23
09283-35023
Сальник
641 ₽/шт
24
24751-14211
Holder, bearing rh
25
02122-06127
Болт
85 ₽/шт
26
24752-14220
Holder, bearing lh
27
02122-06127
Болт
85 ₽/шт
28
26260-14201
Gear, kick starter idle
29
09181-20167
Шайба (20X28X1.0)
1 520 ₽/шт
30
08331-3120A
CIRCLIP
146 ₽/шт
31
27511-14220
Pignon avant (Z=14)
31
27511-14230
SPROCKET,ENGINE(NT:13)
2 854 ₽/шт
31
27511-14240
Pignon avant (Z=15)
32
09180-28003
Entretoise
33
09140-28003
Гайка
4 220 ₽/шт
34
09167-28003
Rondelle (Lock)
35
09280-28004
O RING(D:1.5,ID:27.7)
1 490 ₽/шт
36
27600-14252
Chain, drive (520x112l)
