Главная Каталог товаров Polaris EPC 1994 Polaris ATV Polaris 1994 300 4X4 (W948130) Polaris 1994 ATV SHIFT LINKAGE ASSEMBLY 4x4 300 W948130 (4926762676C006) | SHIFT LINKAGE ASSEMBLY 4x4 300 W948130 (4926762676C006)

SHIFT LINKAGE ASSEMBLY 4x4 300 W948130 (4926762676C006) | SHIFT LINKAGE ASSEMBLY 4x4 300 W948130 (4926762676C006)

SHIFT LINKAGE ASSEMBLY 4x4 300 W948130 (4926762676C006) | SHIFT LINKAGE ASSEMBLY 4x4 300 W948130 (4926762676C006)

Например: 3233195-070

1

3233195-070

GEAR SELECT KNOB HLR BLACK ASM

2

3233079

Vis

3

3133135

DESC NOT_AVAILABLE

4

3233137

ROD,GEAR SELECTOR Substituted by 3233161

5

3233131

STRAP WIRE

6

3233132

Collier

7

3233368

BOOT GEAR SELECTOR

8

3233081

COVER,GEAR SELECTOR

9

3233065

SPRING,HOLDING

10

3233061

STRIKER Substituted by 3233197

11

3233063

CUP BEARING

12

3233084

INTERLOCK BUTTERFLY

13

3233083

SPRING CENTERING

14

3233062

PIN STOP

15

3233069

SPRING DETENT

16

3233060

BULLET DETENT

17

3233371

SWITCH

18

3233082

BODY GEAR SELECTOR

19

3233076

O-Ring

20

3233088

"""SLIDE HIGH/REV."""

21

7512269

Vis

22

7552605

Rondelle

23

3233089

SLIDE LOW

24

3233070

PIN INTERLOCK

25

3233067

PIN,GROOVE

26

3233498

SCREW MAGNIGARD COATED

27

1341133

SELECTOR ASM,GEAR (Incl. 1-20, 28-33)

28

5020748

ROD SHIFT-LINK HIGH

29

5020749

ROD,SHIFT-LINK,LOW

30

7061013

ROD END LH 6MM.

31

7061014

ROD END RH 6MM.

32

7546701

Nut

33

7546702

Nut

34

7546703

Nut (SELF-LOCKING)
