F-13 REAR WHEEL (CH)

F-13 REAR WHEEL (CH)
Например: 06410-KAN-T40
1
06410-KAN-T40
Damper - rear wheel hub
2
40543-KRS-830
(C)ADJUSTER RCHA
3
41201-KPH-C01
SPROCKETFINAL DR
4
42303-KPH-C00
SLEEVEREAR WHEEL
5
42304-KPH-C00
Entretoise
6
42615-KPH-C00
(C)FLANGE SUB ASS
7
42620-KRS-830
COLLARRR AXLE DI
8
42635-KRS-830
(C)HUB SUB ASSYR
9
42650-KPH-C00
(C)WHEEL SUB ASSY (Rear)
10
42653-KRS-830
O-Ring
11
42701-KPH-C00
RIMRR WHEEL
12
42711-KPH-W30
(C)TIRERR
13
42712-KPH-W30
(C)TUBETIRE
14
42713-KPH-W30
(C)FLAPTIRE
15
90128-KFM-900
Stud bolt (8x19,5)
16
90302-KRS-830
NUT, SPECIAL, 6MM
204 ₽/шт
17
90307-KRF-S00
Nut (spec. 12mm)
18
90309-KRS-830
Nut (8 mm)
19
90753-KRS-830
Joint
20
94001-062-000S
Гайка
47 ₽/шт
21
96140-620-1010
Bearing (6201u)
613 ₽/шт
22
96140-620-3010
Bearing (6203u)
771 ₽/шт
23
96140-630-1010
BEARING, RADIAL BALL, 630
24
97282-411-5810
SPOKE SETA10X159
25
97548-411-5710
SPOKE SETA10X158
