7 - CRANKSHAFT

7 - CRANKSHAFT

Например: 12160-43410

1

12160-43410

Rod assy, connecting

2

09159-08033

Гайка

142 ₽/шт

3

12164-33400-0AO

Bearing, crank pin (green)

3

12164-33300-0B0

METAL,CRANK PIN

1 948 ₽/шт

3

12164-33300-0C0

METAL,CRANK PIN

1 948 ₽/шт

3

12164-33300-0D0

Metal,crank pin

4

12220-43410

Crankshaft

5

04221-04089

шпонка ведомой звездочки балансира

81 ₽/шт

6

12229-43400-0A0

Bearing,cranksh (GREEN)

6

12229-43400-0B0

earing,cranksh (BLACK)

6

12229-43400-0C0

Bearing,cranksh (BROWN)

6

12229-43400-0D0

Bearing c.shaft (YELLOW)

6

12229-43400-0E0

Bearing,crankshaft (red)

6

12229-43400-0G0

Bearing,crankshaft (pink)

6

12229-43400-0F0

Bearing,crankshaft (blue)

7

12229-43400-0D0

Bearing c.shaft (YELLOW)

7

12229-43400-0C0

Bearing,cranksh (BROWN)

7

12229-43400-0A0

Bearing,cranksh (GREEN)

7

12229-43400-0B0

earing,cranksh (BLACK)

7

12229-43400-0F0

Bearing, crankshaft (blue)

7

12229-43400-0E0

Bearing, crankshaft (red)

7

12229-43400-0G0

Bearing, crankshaft (pink)

8

12228-43412

PLATE,CRANK THRUST

669 ₽/шт

8

12228-43413

PLATE,CRANK THRUST

669 ₽/шт

8

12228-43415

BEARING,THRUST

669 ₽/шт

8

12228-43416

PLATE,CRANK THRUST

669 ₽/шт

8

12228-43411

PLATE,CRANK THRUST

669 ₽/шт

8

12228-43414

PLATE,CRANK THRUST

307 ₽/шт

9

09283-30047

Oil seal

10

12111-43410

Piston (std)

10

12111-43410-100

Piston (os:1.0)

10

12111-43410-050

Piston (os:0.5)

11

12140-43422

Ring set,piston

11

12140-43422-050

Piston ring set (os:0.5)

11

12140-43422-100

Piston ring set (os:1.0)

12

12151-43400

Палец поршня

3 485 ₽/шт

13

09381-16001

Стопорное кольцо

113 ₽/шт
