49 - FRONT DAMPER (MODEL F)

49 - FRONT DAMPER (MODEL F)
Например: 51130-43405-15T
1
51130-43405-15T
.outer tube, rh (black)
2
51140-43405-15T
.outer tube, lh (black)
3
01411-0830A
Болт
136 ₽/шт
4
51156-40301
Кольцо
275 ₽/шт
5
51158-49000
Rondelle
6
51153-08C20
Сальник
2 040 ₽/шт
7
51158-49500
Шайба
258 ₽/шт
8
51167-01D00
Металическая вставка
598 ₽/шт
9
51110-43420
Tube,fork inner
10
51121-49510
Metal,slide fr
11
51117-38260
O RING
188 ₽/шт
12
51351-43410
.cap
13
51147-16510
BOLT,FORK CYLINDER(10X25)
238 ₽/шт
14
51148-41310
GASKET
170 ₽/шт
15
51195-45420
PIECE,OIL LOCK
1 189 ₽/шт
16
51123-45420
Шайба
250 ₽/шт
17
51125-45420
ПЛАСТ
250 ₽/шт
18
51146-43405
.cylinder
19
51196-43400
Ring,fr fork pi
20
51177-43400
..spring, rebound
21
51171-43410
.spring
22
51173-43400
Seal,dust
23
02112-0408B
Болт
940 ₽/шт
24
51183-03010
Прокладка
149 ₽/шт
25
51132-43400-15T
.holder, axle (black)
26
08310-0008B
Гайка
85 ₽/шт
27
08321-0108B
Пластина замка
81 ₽/шт
28
08322-0108A
Шайба
85 ₽/шт
29
51799-00A00
O-Ring
30
51770-43405
.p.d.f assy
31
07130-0640B
Болт
119 ₽/шт
35
51103-43610
Damper assy, rh
35
51104-43610
Damper assy, lh
