SHOCK ABSORBER DISASSEMBLED

SHOCK ABSORBER DISASSEMBLED
Например: 50180612S1
1
50180612S1
MONOSHOCK CASE TOP
2
46180413
BOLT M20X1 05
3
46180010
Distance bush 10x15/18/24,5x10,5
4
R12012
Ball joint bearing kit top 12mm
11
46180425
O-ring 25x2 NBR70
12
52000085
Autocollant (PDS KTM)
13
50180611S
EXPANSION TANK CPL. 07
15
50180590S
DCC LOW-SPEED SXS CONTROL
16
50180586S2
DCC HIGH-SPEED NR2 CONTROL
18
40140014S
PLUG ALU M10X1 CPL.
19
46810893
O-ring 5,28x1,78 NBR70 black
20
36120151
HS lock screw M5x6
35
50180582S
PRING RET. (SCREW) M56X1 ANO.
36
50180327
HS cylinder-head screw M5x30
37
50180226
INTERMEDIATE RING 50X1,5
40
91210043
SPRING 62 92-250 d13 TITANLOOK
40
91210042
SPRING 88N/MM L250 TITANLOOK
40
91210044
SPRING 97N/MM L250 TITANLOOK
42
50180273
Round-wire snap ring 58,5x2
43
50180607S
pring retainer 61,5x79,1x7,5 cpl.
44
50180352
O-ring 66,27x1,78 Viton70
45
50180141
Piston rod nut 16x1
46
50180099
O-ring 44x,17x1,78 Viton70
47
50180135
Piston ring 47,95x49,95x8
48
50180067
SHIM 16X36X0,25
48
50180057
Shim 16x34x0,2 y5
48
50180056
Shim 16x32x0,2
48
50180063
SHIM 16X28X0,25
48
50180040
SHIM 16X26X0,30
48
50180039
SHIM 16X25X0,30
48
50180038
SHIM 16X24X0,30
48
50180037
SHIM 16X23X0,30
48
50180073
SHIM 16X30X0,30
48
50180074
SHIM 16X32X0,30
48
50180075
SHIM 16X34X0,30
48
50180076
SHIM 16X36X0,30
48
50180077
SHIM 16X38X0,30
48
50180078
SHIM 16X40X0,30
48
50180070
SHIM 16X42X0,25
48
50180072
SHIM 16X28X0,30
57
50180421
Rebound disc 16x43x8 h5
58
50180197
Piston 16,05x49,6x13,5 4,5/7
70
50180513
NEEDLE L=171
71
46811265
O-ring 2,2x1,6 Viton75 green
72
50180435S1
ADAPTOR D50 H29 CPL.
73
50180113
Washer 18,5x43,7x6
74
50180107
Rubber pad rebound 27x48x8 NBR80
75
50180102
Washer 18x22,5x1,5 plastic
76
50180593
SEAL RING QUAD 17.12X2.62 80SH
79
50180103
O-ring 41x5 NBR70
80
46180119
Guide bushing 18x20x12
81
50180082
Dirt scarper 18mm
84
46180013
O-ring 12x1 NBR70
85
50180126
Round-wire snap ring 53x1,75
86
50180580
RESERVOIR CAP D=50 SXS 07
87
50180480
Rubber pad 17x58x59
89
46180006
Adjustment screw slot rebound
90
50180503S1
FORK PART W/ SPINDLE CPL. 07
91
50180462
Threaded bush M10x1,5 h7,5
92
50180297
Rubber plug 8x3,5 NBR50
93
40540603
Steel ball d3
94
48600028
Spring (1,7) l7,9
95
46180005
Screw cap M16x1
96
50180222
O-ring 4x1,5 NBR70
97
46180016
Adjustment screw slot rebound
98
50180751S1
HOCK ABSORBER FLUID 5 LT
99
R12016
EPAIR KIT SXS + 690 RALLY 07
