FRAME

FRAME
Например: 7620300100090
1
7620300100090
FRAME RALLYE 07
2
76203039000
FOOTREST BRACKET RIGHT 07
3
76203038000
FOOTREST BRACKET LEFT 07
5
0912080303
Vis (M8x30)
6
36003014000
Rondelle (Lock)
7
76204066000
CHAIN SLIDING PART 08
8
51103053051
BUSHING 8,2X10X20
9
0025080356S
Vis
10
76203041250
FOOTREST RIGHT RALLY 07
11
76203040250
FOOTREST LEFT RALLY 07
12
54803044000
PIN FOR FOOT PED 51.5X9.8 MM
13
54603041000
FOOTREST SPRING L/S & R/S
14
0125100003
washer DIN 125 A 10.5
15
0094032253
PIN DIN0094-3,2X25 STEEL
16
51005062100
RUBBER GROMMET 30X20-M8X12
17
54603048000
RANGE CHANGE METAL NUT M8
18
76203005030
RADIATOR STRUT
19
76403034000
FUEL TANK SUPPORT PLATE
20
76203006000
ENGINE SUPPORT RIGHT 07
21
76203005000
ENGINE SUPPORT LEFT 07
22
76203005040
CROSS MEMBER CPL. 08
23
76203005031
RUBBER INSERT
24
76203005050
BUSH ENGINE SUPPORT
25
36003014000
Rondelle (Lock)
26
0015080353
Vis
27
76203001066
JOINT PLATE SEAT 07
28
0912060163
AH SCREW DIN0912-M 6X16
29
76203001072
ADAPTER MONOSHOCK ANCHOR BOLT
31
0912100163
Ah screw din0912-m10x16
32
50233041100
Rondelle (Lock)
33
0025080206
Vis
34
76203018000
ELASTOMER BEARING
35
76203019000
COLLAR BUSH FOR ELAST.BEARING
36
55530044000
Nut
37
0912101406
AH SCREW DIN912 M10X140 10.9
38
0912101906
AH SCREW DIN 912 M10X190 10.9
39
76203016000
ELASTOMER BEARING
40
76203017000
COL. BUSH. F. EL. MOT. BEARING
41
76203001091
PUMP RUBBER KP PARABOLIC
42
0985060003
SELF LOCK. NUT DIN0985-M 6
43
76202095051
SLEEVE FOR CHOKE CABLE
44
54804067000
CHAIN SLIDING PIECE 03
45
71003007000
STEERING HEAD LOCK CPL. ZADI
46
76202095000
CHOKE-CABLE l = 235 07
50
58512068100
FIXING SCREW TANK REAR
51
60512063050
NUT F.TANK BRAKET REAR
