Главная Каталог товаров Polaris EPC 2002 Polaris ATV Polaris 2002 XPLORER 400 (A02CG38CA) Polaris 2002 ATV OIL PUMP - A02CG38CA (4970247024D03) | OIL PUMP - A02CG38CA (4970247024D03)

OIL PUMP - A02CG38CA (4970247024D03) | OIL PUMP - A02CG38CA (4970247024D03)

OIL PUMP - A02CG38CA (4970247024D03) | OIL PUMP - A02CG38CA (4970247024D03)

Например: 3085284

0

3085284

PUMP, OIL (Incl. 10-18)

1

3084757

BOLT&WASHER ASM.

2

3085281

COVER OILPUMP CASE

3

3085280

GASKET OILPUMP CASE

4

3085520

CASE, OILPUMP

5

3086777

Damper

6

3086779

Damper

7

3083783

ASM. SCREW & WASHER

8

3083141

CLAMP-HOSE

9

3086776

PIPE,VINYL

10

3083120

Nut

11

3083121

WASHER-SPRING

12

3083445

COLLAR CAMSHAFT

13

3083127

O-Ring

14

3084195

Entretoise

15

3084196

WHEEL

16

3084197

PIN SPRING

17

3084194

Rondelle

18

3083125

SCREW-AIR VENT

19

3085570

SPRING&LEVER SET
