Главная Каталог товаров Polaris EPC 2002 Polaris ATV Polaris 2002 XPLORER 400 (A02CG38CA) Polaris 2002 ATV AIR BOX - A02CG38CA (4970247024A14) | AIR BOX - A02CG38CA (4970247024A14)

AIR BOX - A02CG38CA (4970247024A14) | AIR BOX - A02CG38CA (4970247024A14)

AIR BOX - A02CG38CA (4970247024A14) | AIR BOX - A02CG38CA (4970247024A14)

Например: 5811660

1

5811660

FILTER PRECLEAN.SLEEVE 4

2

7670117

CLIP

3

7527815

SCREW TAPPING

4

5436943

DUCT-AIRBOX COVER 2-STROKE

5

5411422

GASKET INTAKE

6

5812249

FOAM-SEAL,2"X2.75"X.75"

7

5433740

BAFFLE AIR INLET

8

5433051

COVER AIRBOX HYBRID

9

5811659

SEAL AIRBOX CVR HYBRID

10

7515179

Vis

11

7558301

WASHER FLAT

12

7555716

Rondelle

13

5433050

BOX AIR INTAKE HYBRID

14

1253388

ASM-CARB BOOT 400

15

7080643

CLAMP,NOTCHED(10)

16

5810317

PAD,FUELTANK BRKT. Substituted by 8360026

17

7080865

CLAMP SINGLE WIRE .88 ID

18

5411765

CAP,DRAIN,.75 ID

19

5411766

BUMPER,RUBBER

20

7080707

CLAMP BAND NARROW

21

1253355

ASM.-FILTER
