Главная Каталог товаров Polaris EPC 2002 Polaris ATV Polaris 2002 XPLORER 400 (A02CG38CA) Polaris 2002 ATV CARBURETOR - A02CG38CA (4970247024D02) | CARBURETOR - A02CG38CA (4970247024D02)

CARBURETOR - A02CG38CA (4970247024D02) | CARBURETOR - A02CG38CA (4970247024D02)

CARBURETOR - A02CG38CA (4970247024D02) | CARBURETOR - A02CG38CA (4970247024D02)

Например: 3130184

1

3130184

ASM. TOP MIXING CHAMBER

2

3130496

SPRING THROTTLE

3

3130027

PLATE THROTTLE

4

3130508

E-RING

5

3131298

NEEDLE-JET,6DEY12-3 (J8-DEY12)

6

3130355

Rondelle

7

3130199

HOLDER GUIDE

8

3131764

SPRING THROTTLE SS

9

3130328

ASM. PLUNGER

10

3130494

VALVE THROTTLE (1.5)

11

3130429

NEEDLE JET ASM.

12

3130596

RING MAIN JET

13

3130436

SPRING THROT.ADJ.

14

3130447

Rondelle

15

3130009

SCREW THROTTLE STOP

16

3130011

SCREW AIR

17

3130012

SPRING AIR ADJUST

18

3130066

JET PILOT #35

19

3130025

ASM. SCREW & WASHER

20

3130432

SCREW GUIDE

21

3130239

O-Ring

22

3130123

JET MAIN HX.HD#200

23

3130443

BOWL, FLOAT (350)

24

3130430

FLOAT ASM.

25

3130237

CAP

26

3130020

Gasket - float chamber

27

3131385

VALVE-NEEDLE 2.5 (THREADED)

28

3130018

ARM FLOAT

29

3130361

PIN FLOAT

30

3130047

Rondelle

31

3131384

Asm., Carburetor [Incl. 1-31]
