E-5-1 FRONT CRANKCASE COVER(TRX 250TE)

E-5-1 FRONT CRANKCASE COVER(TRX 250TE)

Например: 11330-HM8-A50

1

11330-HM8-A50

COVER COMP., FR. CRANKCAS

2

11335-HM8-A50

COVER COMP., REDUCTION GE

3

11337-HM8-A50

O-RING, REDUCTION GEAR CO

4

11339-HM8-A50

PROTECTOR COMP., ANGLE SE

5

11394-HM8-000

Gasket - clutch cover

6

15231-HM3-670

VALVE, RELIEF

7

15232-HM3-670

SPRING, RELIEF VALVE

8

15235-HM3-670

CAP, RELIEF VALVE

9

15651-HM8-000

GAUGE, OIL LEVEL

10

22820-HN6-000

PLATE COMP., CLUTCH CAM

11

22825-HN0-671

SPRING, CAM PLATE SIDE

12

22830-HB6-000

PLATE COMP., CLUTCH LIFTE

1 294 ₽/шт

13

22840-HM8-000

SUB LEVER COMP., CLUTCH L

14

22846-HB3-000

OLT, CLUTCH ADJUSTING

487 ₽/шт

15

22860-HB3-000

RETAINER COMP., BALL

640 ₽/шт

16

24615-HN0-771

GEAR, REDUCTION (41T/10T)

17

24616-HN0-771

GEAR, REDUCTION (40T/12T)

18

24617-HN0-771

GEAR, REDUCTION (7/43T)

19

31300-HM8-A51

OTOR ASSY., CONTROL

20

PLATE, CORD GUIDE

21

38800-HR3-A21

SENSOR ASSY., ANGLE

22

90116-HP5-600

BOLT, SOCKET, 5X20

22

90116-KCY-671

Vis

353 ₽/шт

23

90485-040-000

WASHER, 8MM

204 ₽/шт

24

91009-HF1-671

Roulement

25

91021-HN0-671

eedle bearing

26

91050-HN0-A11

Roulement

27

91060-HN0-A11

Roulement

28

91070-HN0-A11

Roulement

29

91202-HC0-003

Joint

385 ₽/шт

30

91306-HB3-003

O-Ring

228 ₽/шт

31

91307-KF0-003

O-Ring (18X3 ARAI)

228 ₽/шт

32

91308-HM8-A51

O-RING, 16.8X1.9

33

91351-HM8-A51

O-RING, CONTROL MOTOR

462 ₽/шт

34

94030-08000

Nut

47 ₽/шт

35

94101-05800

Rondelle (5 mm)

39 ₽/шт

36

94301-08100

DOWEL PIN, 8X10

94 ₽/шт

37

94301-08140

Dowel pin (8x14)

94 ₽/шт

38

95701-060-1400

Bolt

55 ₽/шт

39

95701-060-4000

БОЛТ

66 ₽/шт

40

95701-060-4508

БОЛТ ТЕРМОСТАТА

86 ₽/шт
