Cylinder - Head - Piston T

Cylinder - Head - Piston T
Например: AP0223529
1
AP0223529
Cylinder head
8
AP0945751
Break washer a6
9
AP0840861
Vis (M6x25)
10
AP0250025
Gasket
11
AP0222226
ngular union
12
AP0222420
Temp. Sensor
13
AP0945750
Break washer a5
14
AP0240182
Vis
15
AP0922242
ngular union
16
AP0240362
Stud bolt
17
AP0230604
Gasket
18
AP0247955
Rubber spacer
19
AP0242851
Nut
20
AP0840882
Vis
22
AP0232990
in 3x9,8
23
AP0236100
Bush
24
AP0239310
Spring
25
AP0236081
Chain tensioner housing
26
AP0840402
Vis
27
AP0229330
djuster screw int. m18x2,5
28
AP0239180
Spring
29
AP0229320
djuster screw ext.
30
AP0242840
Nut m24x1
31
AP0251010
Collier
32
AP0260141
pipe 240 mm
33
AP0251920
Collier
34
AP0260310
Rubber spacer
35
AP0430782
pc - O-Ring (23,3x2,4)
36
AP0241370
Cover m24x1
37
AP0260961
Couvrir
38
AP0210674
Valves cover
39
AP0236130
Upper chain guide plate
40
2R000244
Cover m16x1,5
41
AP0430622
pc - Gasket ring
42
AP0230540
O-Ring
43
AP0244211
Rondelle
44
AP0941122
Hex screw
45
AP0253591
Valve (IN)
46
AP0253596
Valve (IN)
47
AP0253581
Exhaust valve guide
48
AP0245710
Seeger
49
AP0297433
Molykote G-N 50gr.
50
AP0899784
Loctite (orange) 574
51
AP0297385
Silastic 732RTV 100gr.
