Cylinder - Head - Piston N>S

Cylinder - Head - Piston N>S
Например: AP0223529
1
AP0223529
Cylinder head
8
AP0945751
Break washer a6
9
AP0840861
Vis (M6x25)
10
AP0250025
Gasket
11
AP0222226
ngular union
12
AP0945750
Break washer a5
13
AP0441341
Vis
14
AP0922242
ngular union
15
AP0240360
Stud bolt
16
AP0230604
Gasket
17
AP0242851
Nut
19
AP0840880
Vis
20
AP0229290
in 8x16
21
AP0232990
in 3x9,8
22
AP0250980
Gasket
23
AP0236100
Bush
24
AP0239310
Spring
25
AP0236081
Chain tensioner housing
26
AP0840401
Vis
27
AP0229330
djuster screw int. m18x2,5
28
AP0239180
Spring
29
AP0229320
djuster screw ext.
30
AP0242840
Nut m24x1
31
AP0251010
Collier
32
AP0260141
pipe 240 mm
33
AP0251920
Collier
34
AP0260961
Couvrir
35
AP0210674
Valves cover
36
AP0236130
Upper chain guide plate
37
AP0430600
O-ring 12-1,5 mm
38
AP0241070
Joint m16x1/m16x1,5
39
AP0930500
Joint
40
AP0237080
Tachometer shaft
41
AP0230540
O-Ring
42
AP0244211
Rondelle
43
AP0941121
Hex screw
44
AP0253591
Valve (IN)
45
AP0253596
Valve (IN)
46
AP0253581
Exhaust valve guide
47
AP0245710
Seeger
48
AP0297433
Molykote G-N 50gr.
49
AP0899784
Loctite (orange) 574
50
AP0297385
Silastic 732RTV 100gr.
51
AP0430782
pc - O-Ring (23,3x2,4)
52
AP0241370
Cover m24x1
53
AP0247955
Rubber spacer
54
AP0260310
Rubber spacer
55
AP0222420
Temp. Sensor
