CARBURETOR - C10CL50AA (4978707870D07) | CARBURETOR - C10CL50AA (4978707870D07)

CARBURETOR - C10CL50AA (4978707870D07) | CARBURETOR - C10CL50AA (4978707870D07)

Например: 3130507

1

3130507

RING

2

3130508

E-RING

3

3131224

NEEDLE JET J8-4HB41-3

4

3130752

RING

5

3131443

ASM-DIAPHRAGM

6

3131299

JET-NEEDLE(Q-4M)

7

3130541

Vis

8

3130540

WASHER SPRING

9

3130504

JETBLOCK ASM.

10

3130014

WASHER

11

3130566

MAIN JET #142.5

12

3130515

SEAL

13

LR--

CALIPER, BRAKE, RH

14

3130518

E-RING

15

3130519

CAP

16

3130361

PIN FLOAT

17

3130594

PLATE

18

3130532

Gasket - float chamber

19

3130520

Vis

20

3130590

FLOATBODY ASM.

21

3130521

Vis

22

3130529

FLOAT ASM.

23

3130591

Vis

24

3131360

VALVE-NEEDLE 1.5(PUSH IN)

25

3130533

O-Ring

26

3130624

JET PILOT #40

27

3130522

O-Ring

28

3130523

Rondelle

29

3130525

Spring

30

3130524

ADJUSTER

31

3131423

SCREW-ADJUST

32

3130836

Spring

33

3130502

VALVE THROTTLE 100

34

3130589

Spring

35

3130514

RING

36

3130501

Vis

37

3130513

SHAFT ASM THROTTLE

38

3130543

GUIDE CABLE

39

3130535

Vis

40

3130511

Couvrir

41

3130512

O-Ring

42

3130199

HOLDER GUIDE

43

3130538

Spring

44

3130539

PLUNGER ASM.

45

3130625

JET AIR PILOT #160

46

3131559

ASM-CARBURETOR

47

3084205

ASM. SCREW & WASHER

48

3130505

Spring

49

3131419

ASM-COVER

50

3130924

Vis
