13 - CARBURETOR (MODEL Z)

13 - CARBURETOR (MODEL Z)
Например: 13201-47170
1
13201-47170
Carburetor,lh
2
13202-47170
Carburetor,ml
3
13203-47170
Carburetor,mr
4
13204-47170
Carburetor,rh
5
13500-45111
Diaphragm
6
13394-31210
CLIP,NEEDLE
238 ₽/шт
7
13387-44030
RING
323 ₽/шт
8
13389-44030
Держатель направляющей
868 ₽/шт
9
13503-47070
.spring
10
13581-44030
E RING
489 ₽/шт
11
13383-47090
.needle,jet (5f42-3)
12
13578-47070
CAP
364 ₽/шт
13
02112-05167
Болт
81 ₽/шт
14
13557-47070
GASKET,THROTTLE SHAFT
301 ₽/шт
15
13573-47070
.spring
16
13550-47070
.shaft
17
08310-00087
Гайка 8MM
81 ₽/шт
18
13550-47080
.shaft
19
13563-47070
.pin
20
13606-47070
WASHER,THROTTLE SHAFT
21
13553-47070
.lever
22
13555-47070
.lever
23
13573-47080
.spring
24
13621-47180
.bracket
25
13550-47090
.shaft
26
13651-51011
Seal
231 ₽/шт
27
13617-44080
E RING
231 ₽/шт
28
13557-47070
GASKET,THROTTLE SHAFT
301 ₽/шт
29
13607-47070
Гайка
170 ₽/шт
30
13605-47080
SCREW
512 ₽/шт
31
13605-73000-000
Винт топливный
817 ₽/шт
32
13604-44080
Болт
235 ₽/шт
33
13551-47090
.throttle valve (135)
34
13251-44081-H17
GASKET,FLOAT CHAMBER
958 ₽/шт
35
13382-44030
Шайба
4 110 ₽/шт
36
13388-44030
Пружина
1 143 ₽/шт
37
09492-40007
Jet,pilot
38
13357-44080
PLUG,NEEDLE JET
318 ₽/шт
39
09494-00264
Жиклер игольчатый
1 803 ₽/шт
40
13382-03110
Шайба
178 ₽/шт
41
09491-92004
JET,MAIN(92.5)
594 ₽/шт
42
13247-44080
Болт
669 ₽/шт
43
13246-44080
Прокладка
231 ₽/шт
44
13250-44080
Поплавок
2 307 ₽/шт
45
02112-0406B
Болт
81 ₽/шт
46
13373-11400
Плата клапана
465 ₽/шт
47
13254-92311
PIN,FLOAT
162 ₽/шт
48
13370-44500
Запорная игла поплавковой камеры
3 655 ₽/шт
49
13374-35C00
КОЛЬЦО УПЛОТНИТЕЛЬНОЕ
275 ₽/шт
50
13376-19F00
Фильтр-сеточка
581 ₽/шт
51
13502-47070
.cover
52
13268-44010
.spring
53
13575-47070
.pin
54
13276-31210
.bush
55
13627-44090
.bracket
56
13682-31210
CAP,STARTER VALVE
459 ₽/шт
57
09493-24005
.jet (120)
58
02112-05167
Болт
81 ₽/шт
59
08321-0105A
Пластина замка
81 ₽/шт
60
13550-47100
.shaft
61
13589-47070
Шайба
258 ₽/шт
62
13278-47091
O Ring
210 ₽/шт
63
13210-47180
Flange assy
64
13422-44080
Lever,starter p
65
13605-47070
Болт
407 ₽/шт
66
13410-47070
.shaft
67
02142-0512A
Болт
85 ₽/шт
68
09355-45857-600
Шланг
1 433 ₽/шт
69
13627-47070
.bracket
70
13271-93011
Пружина
204 ₽/шт
71
13685-47070
Золотник
1 975 ₽/шт
72
09352-60104-600
Hose(6X10X600)
1 292 ₽/шт
73
13267-47070
Screw
74
13685-47080
.nipple
75
02112-06127
Болт
81 ₽/шт
75
02122-0612B
Болт
82 ₽/шт
76
13413-49220
.lever
77
13421-49220
.lever
78
13437-49220
.spring
79
13685-47090
Nipple,caburet
80
02142-0510A
Болт
82 ₽/шт
80
02112-0510B
Болт
85 ₽/шт
81
08321-0105A
Пластина замка
81 ₽/шт
82
13432-47090
Шайба
156 ₽/шт
