11C - CARBURETOR (MODEL S/V E18)

11C - CARBURETOR (MODEL S/V E18)
Например: 13201-21EL0
1
13201-21EL0
Carburettor (LH)
2
13202-21EL0
Carburetor assy, ml
3
13203-21EL0
Carburetor assy, mr
4
13204-21EL0
Carburettor (RH)
5
13550-21E30
.shaft, throttle
6
08321-01087
Пластина замка
81 ₽/шт
7
13553-21E10
.lever, throttle
8
13557-47070
GASKET,THROTTLE SHAFT
301 ₽/шт
9
13573-21E10
.spring
10
13573-21E00
.spring
11
13550-21E10
.lever, throttle
12
13550-21E00
.shaft, throttle
13
02112-7516A
Болт
102 ₽/шт
14
08310-00087
Гайка 8MM
81 ₽/шт
15
13550-21E20
.shaft, throttle
16
13553-21E00
.shaft, throttle
17
13502-17E20
COVER,DIAPHRAGM
4 457 ₽/шт
18
13507-17C02
Diaphragm
3 460 ₽/шт
19
13501-33C00
.valve, piston
20
13417-12D00
Пружина
516 ₽/шт
21
13382-42A00
RING
187 ₽/шт
22
13394-40D20
E RING
282 ₽/шт
23
13387-47010
RING
323 ₽/шт
24
13382-44030
Шайба
4 110 ₽/шт
25
13574-32C00
.ring
26
13383-21E00
Жиклер
2 635 ₽/шт
27
13251-33C00
O RING
669 ₽/шт
28
13332-05A10
Шайба
242 ₽/шт
29
09494-00814
.jet, needle (o-8)
30
13331-21E40
RING
469 ₽/шт
31
13602-06C20
Болт
379 ₽/шт
32
13294-33C00
O RING
375 ₽/шт
33
13417-26D00
Пружина
238 ₽/шт
34
13432-47090
Шайба
156 ₽/шт
35
13220-21E00
.holder, jet
36
09491-22013
Жиклер главный (110)
728 ₽/шт
37
13385-33C00
HOLDER,JET
4 590 ₽/шт
38
13418-17C10
HOLDER,GUIDE
954 ₽/шт
39
13418-17C01
ap,starter
323 ₽/шт
40
13411-05320
PLUNGER ASSY
1 396 ₽/шт
41
09493-29002
Jet, air
42
13250-31E00
Float/needle va
43
09492-10002
JET,PILOT(10)
1 451 ₽/шт
44
09491-47001
JET,STARTER(47.5)
1 208 ₽/шт
45
13258-33C00
SEAL
993 ₽/шт
46
13295-29901
O-Ring, Pilot Air Screw
210 ₽/шт
47
13291-29900
Шайба
162 ₽/шт
48
13268-47070
Пружина
272 ₽/шт
49
13279-47070
Винт топливный
884 ₽/шт
50
13602-05A10
Болт
238 ₽/шт
51
13508-17C00
КОЛПАЧОК
1 020 ₽/шт
52
13251-06C10
КОЛЬЦО УПЛОТНИТЕЛЬНОЕ
364 ₽/шт
53
13651-51011
Seal
231 ₽/шт
54
13601-05148-XC0
Винт,5X14
211 ₽/шт
55
13627-31E00
.bracket
56
02122-0510A
Болт
85 ₽/шт
57
02112-05127
Болт
81 ₽/шт
58
13247-02340
Заглушка дренажная
258 ₽/шт
59
13374-35C00
КОЛЬЦО УПЛОТНИТЕЛЬНОЕ
275 ₽/шт
60
13557-07D00
.ring
61
13331-06C20
RING
395 ₽/шт
62
13376-19F00
Фильтр-сеточка
581 ₽/шт
63
13650-25E01
HEATER ASSY,CARBURETOR(15W)
2 550 ₽/шт
64
13650-25E01
HEATER ASSY,CARBURETOR(15W)
2 550 ₽/шт
65
13655-25E00
THERMO SWITCH,CARB HEATER
4 457 ₽/шт
66
09407-14403
КЛЕММА
221 ₽/шт
