Throttle Bodies

Throttle Bodies

Например: T1243406

1

T1243406

hrottle Body, 45mm, Single

1 шт. в узле

2

T1241970

Fuel Rail Assy, High Flow

1 шт. в узле

3

T1242261

Fuel Rail Assy

1 шт. в узле

4

T1241960

Injector Assy, High Flow

2 шт. в узле

5

T1241965

O-Ring (Injector, Upper)

2 шт. в узле

6

T1241966

O-Ring (Injector, Lower)

2 шт. в узле

7

T1241967

Clip, Injector

2 шт. в узле

8

T3200195

Bolt, RHHF, M6 x 68, Slv

2 шт. в узле

8

T3205075

Bolt, HHF, Lghtd, M6 x 65, Slv

2 шт. в узле

9

T1242786

Spacer, Fuel Rail, Aluminium

2 шт. в узле

10

T3200190

Bolt, RHHF, M6 x 25, SLV

4 шт. в узле

11

T1241988

Y Piece, Inlet

1 шт. в узле

12

T1242023

Seal, Intake, 59.75 OD

1 шт. в узле

13

T1242090

Seal, Intake, 53.25 OD

2 шт. в узле

14

T3550634

Washer, 6.4 x 16 x 2

4 шт. в узле

15

T3205093

Bolt, HHF, Lghtd, M6 x 50, Slv

4 шт. в узле

16

T1241955

Cover, Fuel Rail, LH

1 шт. в узле

17

T1241956

Cover, Fuel Rail, RH

1 шт. в узле

18

T3450145

End Tip

2 шт. в узле

19

T1242024

Hose, Fuel Feed, Rubber, Assy

1 шт. в узле

20

T1241982

SPRING CLIP, FUEL RAIL

1 шт. в узле
