Seat Assy & Toolkit

Seat Assy & Toolkit

Например: A9700383

1

A9700383

Seat, Rider, Comfort, Acc

1 шт. в узле

2

T2307368

Rubber Foot, Seat

4 шт. в узле

3

T2311420

Pillion Seat

1 шт. в узле

4

T2307371

Rubber Foot, Seat

4 шт. в узле

5

T2308467

Bracket, Pillion, Seat

1 шт. в узле

6

T2309654

Bolt, Pan Hd, M6 x 18, SS, Enc

4 шт. в узле

7

T3331010

Bolt, But/Hd, Skt, M6 x 16, S/

1 шт. в узле

8

T2307244

Latch, Seat

1 шт. в узле

9

T2310080

Pull Ring, Latch

1 шт. в узле

10

T3330184

Screw, C'sunk Tx, M6 x 25, Slv

2 шт. в узле

11

T2307786

C Spanner, Dia 76mm

1 шт. в узле

12

T2307787

Extension Handle

1 шт. в узле

13

T3334411

Bolt, TX, M10 x 35

2 шт. в узле

14

T2307140

Spacer, Aluminium, Seat Mount

1 шт. в узле

15

T2309807

Seat Lanyard

1 шт. в узле

16

T3331432

Screw, Pan/Hd, Torx, M4 x 18,

1 шт. в узле
