FUEL TANK and CARBURETOR MOUNTING - A04CD32AA/AB/AC/FB (4986268626B03) | FUEL TANK and CARBURETOR MOUNTING - A04CD32AA/AB/AC/FB (4986268626B03)

FUEL TANK and CARBURETOR MOUNTING - A04CD32AA/AB/AC/FB (4986268626B03) | FUEL TANK and CARBURETOR MOUNTING - A04CD32AA/AB/AC/FB (4986268626B03)

Например: 2520409

1

2520409

ASM-FUEL TANK

2

5812123

Gasket

3

2871442

CAP FUEL GAUGE LONG

4

8360009-600

LINE FUEL 1/8 ID 600 CM.

5

5431053

VENT TANK

6

7512277

Vis

7

7558301

WASHER FLAT

8

5222155

BRKT-FUEL COVER MNT RH PLTD

8

5222154

BRKT-FUEL COVER MNT LH PLTD

9

5811899

FOAM-SEAL,17"

10

7542105

NUT HEX

11

7552801

Rondelle (Lock)

12

5245671-067

Bracket, Carburetor Support

13

7547069

NUTSERT HEX

14

7517505

Vis

15

5432559

KNOB FUEL VALVE

16

5432733

NUT FUEL VALVE

17

7052161

VALVE 3-WAY

18

7080003

CLAMP HOSE

19

8450117-250

FUEL HOSE-250 CM

20

3084205

ASM. SCREW & WASHER

21

5245674-067

MOUNT CARBURETOR BLK

22

3110050

MOUNT CARBURETOR

23

7052346

FITTING-FUEL OUTLET RES Z PRS

24

7052362

GROMMET-FLANGED .36X.56X1.06

25

7052350

Fitting, Fuel Outlet, Main

26

7512276

Vis

27

7555859

WASHER FLAT
