Главная Каталог товаров Polaris EPC 2001 Polaris ATV Polaris 2001 XPLORER 400 (A01CG38CA) Polaris 2001 ATV FUEL TANK - A01CG38CA (4963916391A012) | FUEL TANK - A01CG38CA (4963916391A012)

FUEL TANK - A01CG38CA (4963916391A012) | FUEL TANK - A01CG38CA (4963916391A012)

FUEL TANK - A01CG38CA (4963916391A012) | FUEL TANK - A01CG38CA (4963916391A012)

Например: 2520240

1

2520240

"""FUEL TANK STRAIGHT FTGS"""

1

1240082

SUBSTITUTED BY 2520358

2

5811052

FOAM SEAL

3

5450389

Fuel cap

4

5812123

Gasket

5

8360009-600

LINE FUEL 1/8 ID 600 CM.

6

5431053

VENT TANK

7

7512310

Vis

8

5222155

BRKT-FUEL COVER MNT RH PLTD

8

5222154

BRKT-FUEL COVER MNT LH PLTD

9

7512208

Vis

10

2530008

FILTER FUEL

11

8450040-600

LINE FUEL 1/4 ID(600 CM.)

12

7080003

CLAMP HOSE

13

7080534

CLAMP HOSE

14

5220916-067

BRKT,R.TANK MT,BLK.

15

7542324

Nut (SELF-LOCKING)

16

5810317

PAD,FUELTANK BRKT. Substituted by 8360026

17

7052147

ELBOW, MAIN (Yellow)

17

7052150

FITTING FUEL OUT MAIN 4 Y

18

7052348

FITTING-OUTLET 90? RES Z PRS

18

7052149

FITTING FUEL OUT RES. Z

19

7052154

VALVE 3-WAY HORIZ PORTS

20

5432733

NUT FUEL VALVE

21

5432559

KNOB FUEL VALVE

22

7517505

Vis
