Главная Каталог товаров Polaris EPC 1992 Polaris ATV Polaris 1992 TRAIL BOSS 4X4 (W928127) Polaris 1992 ATV FRAME ASSEMBLY w/ RACKS 250 4x4 / W928127 (4922872287A007) | FRAME ASSEMBLY w/ RACKS 250 4x4 / W928127 (4922872287A007)

FRAME ASSEMBLY w/ RACKS 250 4x4 / W928127 (4922872287A007) | FRAME ASSEMBLY w/ RACKS 250 4x4 / W928127 (4922872287A007)

FRAME ASSEMBLY w/ RACKS 250 4x4 / W928127 (4922872287A007) | FRAME ASSEMBLY w/ RACKS 250 4x4 / W928127 (4922872287A007)

Например: 7515304

1

7515304

SCREW-FLANGED

2

7555716

Rondelle

3

5010192

BUSHING

4

5412508

DAMPENER-VIBRATION

5

5243468-067

BRKT SUPPORT RACK LH BLK

5

5220901-067

BRKT,RH SUPPORT RACK Substituted by 5243469-067

6

7558402

WASHER FLAT

7

5220902-067

SUPPORT R.FENDER

8

5410436

Rondelle (Rubber)

10

1040253-067

FRAME,SQUARE(91'4X4') [No Longer Available]

11

5810455

PAD

12

7512252

SCREW(10)

13

7621229

RIVET

14

5431023

COVER,BRKT,BUMPER MT.

15

5431013-157

CAP,BUMPER,FR,BON.BLUE

16

7073455

DECAL, F.SUSP.

17

2670135-067

RACK,FRT.BLK.

18

7661401

PIN COTTER

19

7515355

Vis

20

7542327

NUT NYLOK

21

7512232

Vis

22

5222272-067

GUARD, ROCK, BLK.

23

7661825

RIVET

24

2670134

ASM. REFLECTOR AMBER

25

5431484

TRIM, FOOTREST

26

1040274-117

FOOTPAD,LH,SILVER

26

1040275

FOOTPAD,RH,(ATV) Substituted by 1040275-117

27

7661637

RIVET INTERLOCK Z

28

7542324

Nut (SELF-LOCKING)

29

2670136-067

RACK REAR BLK.

30

5430823

CAP, BUMPER, 4 WHL.(10) Substituted by 5410794

31

7555827

Rondelle

32

7661103

PIN COTTER

33

5224385

ROD,BRAKE LINKAGE Substituted by 5224447

34

7042029

Spring

35

1910054-067

PEDAL, BRAKE

36

7661416

PIN, SPIRAL(10)

37

5130715-067

PEDAL FOOT

38

7558702

WASHER THRUST

39

5431107

BUSHING PEDAL PIVOT

40

2670113-067

BUMPER,FR,(BLK.)

41

7512329

Vis

42

5410012

PLUG RUBBER-HOLE .5DIA

43

2670133

REFLECTOR ASM RED

44

5810467

PLUG FRAME

46

5211359-067

GUARD,CLUTCH,INNER

47

5222860-067

GUARD,CLUTCH,OUTER
