FRAME

FRAME
Например: 5730300104430
1
5730300104430
FRAME CPL. 660SM FACTORY 02
2
57303002000
% sub frame alu 660 sm fact.
4
50303002182
PLUG-IN CAP SW14 99
6
0019080206S
Vis (Flat M8x20)
7
0019080266S
Vis (M8x26)
8
59001037000
Vis (spec)
9
0934080003
Nut
11
58003012000
SPACER ROLLER 10,3X20X22
12
71001012100
PVC CAP D=22MM
14
58303055000
ENGINE SUPPORT AGW '94
16
0931101103
HH SCREW DIN0931-M10X110
17
49009082000
flanged hex nut DIN 6927 M10 WS15
18
49109481052
Vis
19
54310086200
Nut (M8x10,9)
30
0931100603
HH SCREW DIN0931-M10X60
31
0985100003
SELF LOCKING NUT DIN0985-M10
32
0912101603
AH SCREW DIN0912-M10X160
34
55530044000
Nut
36
50335030001
PVC-HOSE 6X9
37
50303089000
ANGLE PIECE '97
38
5830303800030
Footrest bracket l/s black
5 480 ₽/шт
40
5830304000030
Footrest l/s black
3 650 ₽/шт
41
5460314000030
Footrest r/s black
3 785 ₽/шт
42
58303041000
FOOTREST SPRING L/S '93
43
54603041000
FOOTREST SPRING L/S & R/S
44
58303044000
BOLT FOR FOOTREST
45
54803044000
PIN FOR FOOT PED 51.5X9.8 MM
46
0125100003
washer DIN 125 A 10.5
47
0094032253
PIN DIN0094-3,2X25 STEEL
51
58303045044
FOOTREST RUBBER CPL. '94
58
0985060003
SELF LOCK. NUT DIN0985-M 6
59
51103053000
CHAIN SLIDING PIECE BELOW '97
60
51103053051
BUSHING 8,2X10X20
61
54403135000
PLASTIC CAP SFL10
63
58303063000
BRAKE LEVER STOP '93
64
0991060202
FLAT HEAD DIN7991-M 6X20
68
0025080256
Vis
70
0025080306
Vis
79
57331096052
CONNECT. FOR VENTILATION M6 02
80
57303096000
OVERFLOW RESERVOIR SUPERM. 02
