F-38-10 REAR FINAL GEAR

F-38-10 REAR FINAL GEAR
Например: 06910-HR6-B00
1
06910-HR6-B00
EARING SET, NEEDLE
2
12361-035-000
Vis de vidange d'huile
3
40200-HR3-A20
SHAFT COMP., RR. PROPELLE
4
40215-HR3-A20
SPRING, SHAFT
5
40300-HR3-A20
JOINT ASSY., YOKE
6
40321-HR0-F00
BOOT, YOKE JOINT
7
40322-HN8-000
BAND A, YOKE JOINT BOOT
8
40323-HN8-000
BAND B, YOKE JOINT BOOT
9
41300-HR3-WB0
GEAR ASSY., RR. FINAL
10
41311-HR3-WB0
CASE SUB ASSY., FINAL GEA
11
41320-HR3-A20
COVER SUB ASSY., FINAL GE
12
41405-HA7-670
RING, STOPPER
236 ₽/шт
13
41421-HP5-600
GEAR, RR. PINION (20T)
14
41431-HP0-A00
GEAR, RR. RING (41T)
15
41436-MB0-310
PIN, RING GEAR STOPPER
1 662 ₽/шт
16
41438-MB0-310
SHIM B, STOPPER PIN (0.15
425 ₽/шт
16
41437-MB0-310
SHIM A, STOPPER PIN (0.10
425 ₽/шт
17
41546-HA0-000
SPACER G, RING GEAR (2.18
17
41541-HA0-000
SPACER B, RING GEAR (1.88
17
41540-HA0-000
SPACER A, RING GEAR (1.82
912 ₽/шт
17
41543-HA0-000
SPACER D, RING GEAR (2.00
17
41545-HA0-000
SPACER F, RING GEAR (2.12
17
41544-HA0-000
SPACER E, RING GEAR (2.06
17
41548-HA0-000
SPACER I, RING GEAR (2.30
17
41547-HA0-000
SPACER H, RING GEAR (2.24
17
41542-HA0-000
SPACER C, RING GEAR (1.94
18
42311-HR3-A20
SHAFT, RR. AXLE
19
50355-HR3-A20
PLATE, SKID
20
50358-HM8-B40
COLLAR, SKID PLATE
21
52112-HA0-000
STOPPER, L. BEARING
1 195 ₽/шт
22
90109-371-000
BOLT, SEALING, 8MM
385 ₽/шт
23
90131-GW0-750
Vis
291 ₽/шт
24
90133-HP5-600
Vis
25
90134-HP5-600
Vis
26
90186-HM8-B40
Vis
27
90242-MB0-000
Nut (64 MM)
2 254 ₽/шт
28
90471-580-000
Gasket (8 mm)
157 ₽/шт
29
91053-HR3-W51
BEARING RADIAL BALL
30
91251-HR0-F01
OIL SEAL, 39X70X12
31
91252-HA0-004
Joint
760 ₽/шт
32
91252-HA0-004
Joint
760 ₽/шт
33
91302-001-020
O-Ring
381 ₽/шт
34
91355-759-003
O-Ring
116 ₽/шт
35
95002-02650
Collier
50 ₽/шт
36
TUBE, 3.5X725
37
96100-600-7300
Bearing (6007)
1 195 ₽/шт
