Главная Каталог товаров Polaris EPC 2000 Polaris ATV Polaris 2000 SPORTSMAN 500 (A00CH50AA) Polaris 2000 ATV CRANKSHAFT and PISTON - A00CH50AK (4954805480D011) | CRANKSHAFT and PISTON - A00CH50AK (4954805480D011)

CRANKSHAFT and PISTON - A00CH50AK (4954805480D011) | CRANKSHAFT and PISTON - A00CH50AK (4954805480D011)

CRANKSHAFT and PISTON - A00CH50AK (4954805480D011) | CRANKSHAFT and PISTON - A00CH50AK (4954805480D011)

Например: 3087224

1

3087224

SET PISTON RING STANDARD

1

3087225

Kir segment (0.25MM O/S)

1

3087226

Kir segment (0.50MM O/S)

2

3087172

Piston (0.50MM O/S)

2

3087170

SET PISTON STANDARD

2

3087171

Piston (0.25MM O/S)

3

LR--

CALIPER, BRAKE, RH

4

3085534

CLIP

5

3085374

CRANKSHAFT#2,PTO SIDE

6

3085375

PIN-CRANK COMPL.

7

3085376

ROD CONNECTING

8

3085400

BEARING LARGE END

9

3085024

BALL STEEL

10

3085373

CRANKSHAFT#1,MAG SIDE

10

3085399

CRANKSHAFT ASM. (Incl. 5-11, 19)

11

3085852

BALANCER,GEAR,1 *

12

3085404

SHAFT BALANCER

13

3084896

SPACER 1.0

13

3084897

SPACER 1.2

13

3084895

SPACER 0.8

14

3084893

SPACER 1.0

14

3084892

SPACER 0.8

14

3084894

SPACER 1.2

14

3240088

SPACER 0.6

15

3084882

SPROCKET 1

16

3085528

NUT SLIT

17

3086767

Rondelle

18

3083905

NUT LOCK

19

3085346

PIN, DOWEL

20

3081447

KEY

21

3081543

KEY WOODRUFF
