Clutch

Clutch

Например: T1179666

1

T1179666

Clutch Assembly (35/35), Grade B

1 шт. в узле

2

T1172610

Bolt, M6 x 35

3 шт. в узле

3

T1172009

Stopper Plate

1 шт. в узле

4

Clutch Spring

5

T1172008

Seat, Clutch Spring

3 шт. в узле

6

T1179005

Clutch Pressure Plate

1 шт. в узле

7

T1172004

Disk, Clutch Friction

3 шт. в узле

8

T1172010

Plate, Clutch

1 шт. в узле

8

T1170575

Plate, Clutch Pressure

1 шт. в узле

8

T1170554

Plate, A, Clutch

7 шт. в узле

9

T1170554

Plate, A, Clutch

7 шт. в узле

10

T1179960

Disk, Clutch Friction

7 шт. в узле

11

T1179004

Centre, Clutch

1 шт. в узле

12

T1170912

Spring, Judder

1 шт. в узле

13

T1172007

Rondelle (Clutch)

1 шт. в узле

14

T1179002

Outer Comp, Clutch

1 шт. в узле

15

T1179090

Sprocket, Aux Drive

1 шт. в узле

16

T1172442

Bearing, Needle, 32 x 37 x 17.8

2 шт. в узле

17

T1177930

hrust Washer

1 шт. в узле

18

T1172002

Plate, Clutch

1 шт. в узле

19

T3800012

Bearing Ball

1 шт. в узле

21

T1179696

Lifter Piece

1 шт. в узле

22

T1170106

Nut, Clutch, 22mm

1 шт. в узле

23

T1179999

Washer, C, Clutch

1 шт. в узле

24

T1171282

Washer, ID 22, OD 34

1 шт. в узле

25

T1179016

Lifter Arm

1 шт. в узле

26

T1179011

Lifter Shaft

1 шт. в узле

27

T1175599

Return Spring, Clutch

1 шт. в узле

28

T3050339

Screw, Cap/Hd, M6x 20, Slv, En

1 шт. в узле

29

T1179200

Clutch Spring Kit

1 шт. в узле

30

T1179007

Friction clutch plates kit

1 шт. в узле

31

T1179040

Bracket, Clutch, Slave

1 шт. в узле

32

T1179023

Adjuster, Slave Cyl, Clutch

1 шт. в узле

33

T1179025

Dust Seal, Gaiter

1 шт. в узле

34

T1179777

Slave Cylinder, Clutch, Kit

1 шт. в узле

35

T1179035

Nipple, Clutch, Slave

1 шт. в узле

36

T3259003

Cap, Nipple, Bleed

1 шт. в узле

37

T3259002

Nipple, Bleed

1 шт. в узле

38

T3259001

Bolt, Bleed, M6 x 11.5

1 шт. в узле

39

T3559006

Washer

2 шт. в узле

40

T1179024

Plate, Spring, Detent

1 шт. в узле

41

T3330649

Screw, Pan/Hd, Tx, M5 x 12, Sl

1 шт. в узле
