Главная Каталог товаров Polaris EPC 1996 Polaris ATV Polaris 1996 MAGNUM 2X4 (W967544) Polaris 1996 ATV CARBURETOR Magnum 2X4 W967544 (4936033603D002) | CARBURETOR Magnum 2X4 W967544 (4936033603D002)

CARBURETOR Magnum 2X4 W967544 (4936033603D002) | CARBURETOR Magnum 2X4 W967544 (4936033603D002)

CARBURETOR Magnum 2X4 W967544 (4936033603D002) | CARBURETOR Magnum 2X4 W967544 (4936033603D002)

Например: 3130507

1

3130507

RING

2

3130508

E-RING

3

3130528

JET NEEDLE(5F81-3)

4

3130752

RING

5

3130506

DIAPHRAGM ASM.

6

3130510

NEEDLE JET (P-8)

7

3130541

Vis

8

3130540

WASHER SPRING

9

3130504

JETBLOCK ASM.

10

3130014

WASHER

11

3130527

MAIN JET #140

12

3130515

SEAL

13

LR--

CALIPER, BRAKE, RH

14

3130518

E-RING

15

3130519

CAP

16

3130361

PIN FLOAT

17

3130534

FILTER

18

3130533

O-Ring

19

3131360

VALVE-NEEDLE 1.5(PUSH IN)

20

3130594

PLATE

21

3130591

Vis

22

3130532

Gasket - float chamber

23

3130520

Vis

24

3130590

FLOATBODY ASM.

25

3130521

Vis

26

3130529

FLOAT ASM.

27

3130524

ADJUSTER

28

3130525

Spring

29

3130523

Rondelle

30

3130522

O-Ring

31

3130624

JET PILOT #40

32

3130546

SCREW ADJ

33

3130545

RING

34

3130544

Spring

35

3130502

VALVE THROTTLE 100

36

3130589

Spring

37

3130514

RING

38

3130501

Vis

39

3130513

SHAFT ASM THROTTLE

40

3130543

GUIDE CABLE

41

3130535

Vis

42

3130511

Couvrir

43

3130512

O-Ring

44

3130199

HOLDER GUIDE

45

3130538

Spring

46

3130539

PLUNGER ASM.

47

3130625

JET AIR PILOT #160

48

3130724

Carburettor

49

3084205

ASM. SCREW & WASHER

50

3130505

Spring

51

3130503

ASM. COVER

52

3130924

Vis
