87 - REAR WHEEL (GSX250Z/D E24, GSX250SZ E24)

87 - REAR WHEEL (GSX250Z/D E24, GSX250SZ E24)

Например: 64110-37301

1

64110-37301

Hub, rear

2

64210-44060

Panel, rear hub

3

64410-11320-XNA

Shoe,brake

4

55420-30000

SPRING

221 ₽/шт

5

54440-08004

CAM,BRAKE

1 376 ₽/шт

6

09280-15003

КОЛЬЦО УПЛОТНИТЕЛЬНОЕ

204 ₽/шт

7

09160-15048

Шайба

102 ₽/шт

8

64451-44400

Lever,rr brake

9

09118-06086

Болт 6X25

1 680 ₽/шт

10

08321-01067

Шайба, стопорная

81 ₽/шт

11

64711-44400

Axle, rear

12

09180-17043

Spacer 17x25x10

13

09180-17042

Spacer 17x30.5x

14

09160-17050

Шайба

1 250 ₽/шт

15

09141-16001

Nut

16

04111-4030A

Шпонка

85 ₽/шт

17

08143-63037

Подшипник

1 308 ₽/шт

18

08143-62037

BEARING

1 122 ₽/шт

19

09180-17056

Entretoise

20

64611-44001

Drum, sprocket mountin

21

64651-11300

ABSORBER,RR HUB SHOCK

4 845 ₽/шт

22

64733-3300V

SPACER,RR HUB BEARING

23

08113-62057

Подшипник B1 25X52X15

1 584 ₽/шт

24

09285-30003

Seal,oil(30.5X52X8)

1 623 ₽/шт

25

61410-47200

Adjuster,chain

26

09104-08034

BOLT

1 840 ₽/шт

27

08310-00087

Гайка 8MM

81 ₽/шт

28

61433-3100V

SUPPORTER,CHAIN ADJUSTER

29

01550-08507

БОЛТ

2 070 ₽/шт

30

64511-11510

Sprocket, rear (nt:46)

31

09119-10021

Vis

32

09169-10006

Шайба

268 ₽/шт

33

09140-10026-XC0

Гайка

1 130 ₽/шт

34

65100-44130

Tire (3.50s18)

34

65100-44111

Tire (3.50s18)

35

65200-18010

Tube, inner

36

55261-26F10

PROTECTOR,INNER TUBE

486 ₽/шт

37

65311-18420

Rim,rr wheel

38

65320-11300

Spoke set,rr

39

55411-26G00

Балансир колеса

399 ₽/шт

39

55413-41F00

BALANCER,WHEEL(30G)

469 ₽/шт
