17 - CARBURETOR (MODEL D)

17 - CARBURETOR (MODEL D)
Например: 13201-11520
1
13201-11520
Carburetor, lh
1
13201-11530
Carburetor, lh
1
13201-11570
Carburetor, lh
1
13201-11560
Carburetor, lh
1
13201-11540
Carburetor, lh
2
13202-11520
Carburetor, rh
2
13202-11530
Carburetor, rh
2
13202-11570
Carburetor, rh
2
13202-11560
Carburetor, rh
2
13202-11540
Carburetor, rh
3
09491-26019
JET,POWER(132.5)
1 189 ₽/шт
3
09491-27008
Жиклер главный (135)
790 ₽/шт
4
13573-11400
.spring
5
13574-45110
.ring
6
13550-11400
.shaft
7
13550-11410
.shaft
8
13573-11410
.spring
9
02112-05127
Болт
81 ₽/шт
10
08321-0105A
Пластина замка
81 ₽/шт
11
13627-11500
.bracket
12
02112-0420A
Болт
85 ₽/шт
13
08321-0104A
Пластина замка
82 ₽/шт
14
09492-17009
Jet,pilot
15
13604-44080
Болт
235 ₽/шт
16
13551-11400
.valve, throttle
16
13551-11420
.valve, throttle
17
13251-11401
GASKET,FLOAT CHAMBER
880 ₽/шт
18
13250-44080
Поплавок
2 307 ₽/шт
19
09494-00306
Жиклер игольчатый
1 994 ₽/шт
19
09494-00308
.jet, needle (p-3)
20
13382-03110
Шайба
178 ₽/шт
21
09491-23017
JET,MAIN(117.5)
790 ₽/шт
21
09491-23011
JET,MAIN(115)
1 777 ₽/шт
21
09491-22015
JET,MAIN(112.5)
790 ₽/шт
22
13682-09210
CAP,PLUNGER
221 ₽/шт
23
09280-08014
O RING(D:1.5,ID:8.5)
1 560 ₽/шт
24
13268-47070
Пружина
272 ₽/шт
25
13279-47070
Винт топливный
884 ₽/шт
26
13291-29900
Шайба
162 ₽/шт
27
13295-29901
O-Ring, Pilot Air Screw
210 ₽/шт
28
13246-44080
Прокладка
231 ₽/шт
29
13247-44080
Болт
669 ₽/шт
30
13502-11400
.cover
31
13503-44080
Spring
32
13389-44030
Держатель направляющей
868 ₽/шт
33
13500-11410
Diaphragm,carbu
33
13500-11970
.diaphragm
34
13581-44030
E RING
489 ₽/шт
35
13387-47010
RING
323 ₽/шт
36
13394-31210
CLIP,NEEDLE
238 ₽/шт
37
13382-44030
Шайба
4 110 ₽/шт
38
13383-11430
Needle,jet
38
13383-44200
Needle, jet (5D69-4)
39
13376-19F00
Фильтр-сеточка
581 ₽/шт
40
13374-35C00
КОЛЬЦО УПЛОТНИТЕЛЬНОЕ
275 ₽/шт
41
13370-44500
Запорная игла поплавковой камеры
3 655 ₽/шт
42
02112-0406B
Болт
81 ₽/шт
43
13254-92311
PIN,FLOAT
162 ₽/шт
44
13373-11400
Плата клапана
465 ₽/шт
45
13574-11400
.ring
46
02142-0510A
Болт
82 ₽/шт
46
02112-0510B
Болт
85 ₽/шт
47
08321-0105A
Пластина замка
81 ₽/шт
48
13651-51011
Seal
231 ₽/шт
49
13557-47070
GASKET,THROTTLE SHAFT
301 ₽/шт
50
13617-44080
E RING
231 ₽/шт
51
13578-47070
CAP
364 ₽/шт
52
13268-44010
.spring
53
13575-47070
.pin
54
13607-47070
Гайка
170 ₽/шт
55
13605-47080
SCREW
512 ₽/шт
56
13388-44030
Пружина
1 143 ₽/шт
57
13692-11400
.clip, hose
58
13281-11400
.net
59
13210-11500
Flange assy
60
13422-11400
.lever
61
13685-11400
.nipple
62
09352-50005-600
ШЛАНГ
436 ₽/шт
63
02112-05127
Болт
81 ₽/шт
64
08321-0105A
Пластина замка
81 ₽/шт
65
02112-3616A
Болт
1 210 ₽/шт
65
02112-0616A
Болт
81 ₽/шт
66
08321-01067
Шайба, стопорная
81 ₽/шт
67
13267-11400
.adjuster
68
13681-44110
.bush
69
13627-44120
BRACKET
1 224 ₽/шт
70
02112-0508A
Винт №1
85 ₽/шт
71
08321-0105A
Пластина замка
81 ₽/шт
72
13271-93011
Пружина
204 ₽/шт
73
13410-44500
Shaft
74
13605-09300
SCREW,THROTTLE ADJUST
75
09355-45857-600
Шланг
1 433 ₽/шт
76
13432-47090
Шайба
156 ₽/шт
77
09352-50005-600
ШЛАНГ
436 ₽/шт
78
13413-11940
.lever
79
13413-11950
.lever
80
13417-18630
SPRING
411 ₽/шт
