10 - CRANKSHAFT

10 - CRANKSHAFT

Например: 12160-11400

1

12160-11400

Rod assy, connecting

2

09159-08033

Гайка

142 ₽/шт

3

12164-33300-0A0

Metal,crank pin

3

12164-33300-0B0

METAL,CRANK PIN

1 948 ₽/шт

3

12164-33300-0C0

METAL,CRANK PIN

1 948 ₽/шт

3

12164-33300-0D0

Metal,crank pin

3

12164-33210-050

Plane bearing - connecting rod

3

12164-33210-025

Bearing, crank pin (black)

1 924 ₽/шт

4

12220-11401

Crankshaft

5

04221-03059

PIN

900 ₽/шт

6

12229-43400-0C0

Bearing,cranksh (BROWN)

6

12229-43400-0D0

Bearing c.shaft (YELLOW)

6

12229-43400-0B0

earing,cranksh (BLACK)

6

12229-43400-0A0

Bearing,cranksh (GREEN)

6

12229-11400-050

Metal,crankshaf

6

12229-11400-025

Metal,crankshaf

7

21111-11400

Gear, primary drive (nt:24)

8

09140-24007

ШАЙБА

2 390 ₽/шт

9

09164-25001

Шайба

2 540 ₽/шт

10

08341-M3105-9

Woodruff key

11

09283-22015

SEAL,OIL(22X40X8)

1 326 ₽/шт

12

12111-11404

Piston 60.00mm

12

12140-43422

Ring set,piston

12

12111-11410

Piston (std)

12

12111-11410-050

Piston (os:0.5)

12

12140-43422-100

Piston ring set (os:1.0)

12

12103-11820-100

PISTON SET(OS:1.0)

20 487 ₽/шт

12

12103-11820-050

Piston set 0,5

13

12140-11421

Kir segment (STD)

13

12140-11410

Piston ring set (std)

13

12140-11410-050

Piston ring set (os:0.5)

13

12140-11421-050

Кольца поршневые (0.50Mm O/s)

4 692 ₽/шт

13

12140-11421-100

Piston ring set (os:1.0)

14

12151-60D00

Палец поршня

1 309 ₽/шт

15

09381-16001

Стопорное кольцо

113 ₽/шт
