Главная Каталог товаров SUZUKI EPC 700 cm³ - 1099 cm³ SUZUKI GS 850 SUZUKI GS850G D SUZUKI 8 - CRANKSHAFT

8 - CRANKSHAFT

8 - CRANKSHAFT

Например: 12200-45104

1

12200-45104

Vilebrequin

2

12161-45101

.rod, connecting

3

09160-29008

.washer

4

09160-29009

.washer

5

09263-29002

Roller bearing

6

12220-45100

.crankshaft, rh

7

12231-45100

.web, crankshaft rh

8

12241-45100

.crankshaft, middle rh

9

12271-45100

.crankshaft, middle lh

10

12250-45100

.web, crankshaft middle

11

12261-45101

.crankshaft lh

12

12290-45100

.web, crankshaft lh

13

12281-45100

.shaft, timing chain drive

14

09262-30033

Ball bearing 30

15

08331-31309

CIRCLIP

170 ₽/шт

16

21111-45100

.gear, primary drive (nt:49)

17

04221-08129

Крюк

97 ₽/шт

18

08211-28403

.washer

19

09264-32009

Roulement

20

09390-72004

C ring

21

04221-07129

PIN

1 060 ₽/шт

22

09283-30021

SEAL,OIL(30X72X11)

5 015 ₽/шт

23

09289-48002

SEAL,OIL(47.3X60X6.5)

2 125 ₽/шт

24

12111-45110

Piston (STD)

24

12103-45830-050

Piston set 0,5

24

12111-45110-100

Piston (os:1.0)

25

12140-45121

Kir segment (STD)

25

12140-45121-050

Ring set, piston (os:0.5)

25

12140-49001

Kir segment (1 mm)

26

12151-29001

Палец поршня

708 ₽/шт

27

09381-16001

Стопорное кольцо
