52 - FRONT WHEEL (VS750GLEFG/GLEPG)

52 - FRONT WHEEL (VS750GLEFG/GLEPG)
Например: 54111-38A10-23W
1
54111-38A10-23W
Hub assy, front (mt2.15x19) (silver)
2
08123-63027
Подшипник
2 976 ₽/шт
3
09180-15004
SPACER(15.3X21.7X65)
6 690 ₽/шт
4
54711-38A01
xle front
5
54741-38A00
Spacer, axle rh
6
09159-12021
Nut
7
54791-38A00
Cotter pin
8
54600-49260
BOX ASSY,SPEEDOMETER GEAR
17 751 ₽/шт
9
54750-38A20
Spacer, axle lh
10
59211-38A10
Disque de frein
11
09106-08049
BOLT(8X25.5)
2 270 ₽/шт
12
55100-38A20
Tire, front (100/90/19 57h)
13
43130-78030-000
VALVE,TIRE TR413 BS
1 324 ₽/шт
14
55411-17G00
BALANCER,WHEEL(10G)
272 ₽/шт
14
55412-17G00
BALANCER,WHEEL(20G)
272 ₽/шт
14
55412-45100
Balancer,wheel
