Главная Каталог товаров SUZUKI EPC 125 cm³ - 349 cm³ SUZUKI DR 250 SUZUKI DR250S E SUZUKI 5 - CRANKSHAFT

5 - CRANKSHAFT

5 - CRANKSHAFT

Например: 12200-38201

1

12200-38201

Vilebrequin

2

12161-38201

ROD,CONNECTING

8 876 ₽/шт

3

12211-38211

Палец шатунный

2 776 ₽/шт

4

09263-31004

BEARING(31X39X21)

7 990 ₽/шт

5

09160-31002

Шайба

4 140 ₽/шт

6

12221-38200

Crankshaft,rh

7

12261-38200

.crankshaft,lh

8

12661-38202

GEAR,CRANK BALANCER DRIVE

9 306 ₽/шт

9

09209-12006

PIN

3 790 ₽/шт

10

09262-30077-000

Подшипник B1 30X72X19

4 165 ₽/шт

11

09282-14001

SEAL,OIL(14X26X6)

1 374 ₽/шт

12

12548-38200

RETAINER,CRANKSHAFT BEARING,R

301 ₽/шт

13

02122-0510A

Болт

85 ₽/шт

14

12731-38200

SPROCKET,CAM CHAIN DRIVE(NT:21

3 284 ₽/шт

15

12749-32400

KEY,SPROCKET

927 ₽/шт

16

21111-38200

GEAR,PRIMARY DRIVE NO.21

4 262 ₽/шт

17

09140-20013

Гайка

2 540 ₽/шт

18

09164-20003

Пластина замка

1 840 ₽/шт

19

09421-07002

KEY

1 920 ₽/шт

20

12111-38201-0F0

PISTON

7 898 ₽/шт

20

12111-38211

Piston (std)

20

12103-38860-100

20

12103-38860-050

20

12100-38200-050

Набор поршня, OS:0.50

19 727 ₽/шт

20

12100-38200-100

Piston kit (OS: 1.0)

21

12140-49270

Поршневые кольца

12 062 ₽/шт

21

12140-38240

Ring set,piston (std)

21

12140-38240-100

Ring set,piston (os:1.0)

21

12140-38240-050

Ring set,piston (os:0.5)

21

12140-49221-100

Ring set,piston (os:1.0)

21

12140-49270-050

RING SET,PISTON(OS:0.50)

6 021 ₽/шт

22

12151-15501

PIN,PISTON

2 040 ₽/шт

23

09381-18002

Стопор

119 ₽/шт
