31 - FRONT WHEEL (MODEL L/M E41)

31 - FRONT WHEEL (MODEL L/M E41)

Например: 54140-29C00-35W

1

54140-29C00-35W

heel, front (1.85x10)(gray)

1

54140-29C00-28W

heel, front (1.85x10)(white)

1

54140-29C00-019

Wheel, front (1.85x10)(black)

1

54140-29C00-13L

Wheel, front (1.85x10)(silver)

1

54140-29C00-14B

Wheel, front (1.85x10)(gold)

3

54732-29C00

Support, spacer

4

09262-10013

Bearing

5

09285-16005

Seal,oil(16X30X8)

954 ₽/шт

6

54711-16B00

EIXO FRENTE

7

54741-16B00

SPACER,FR AXLE,R

446 ₽/шт

8

08319-31107

Гайка

210 ₽/шт

9

65100-29C10

Tire (3.00x10-2pr)(irc)

10

65200-11B10

Tube assy, wheel inner (irc)

11

54210-29C00-35W

Panel, front brake ancher (gray)

11

54210-29C00-28W

Panel, front brake ancher (white)

11

54210-29C00-019

Panel, front brake ancher (black)

11

54210-29C00-13L

Panel, front brake ancher (silver)

11

54210-29C00-14B

Panel, front brake ancher (gold)

12

09160-05001-A05

Шайба,5.1X9X0.4

119 ₽/шт

13

54621-16B00

Pinion,speedome

14

54632-09400

Bushing, pinion outer

15

54217-16B00

COVER.FR BK AHR PNL BOSS

16

54611-16B01

GEAR,SPEEDOMETER(NT:23)

2 295 ₽/шт

17

54225-16B00

Spacer, panel boss

18

09285-34002

SEAL,OIL(34X42X5)

274 ₽/шт

19

54400-39820

SHOE SET,BRAKE

2 717 ₽/шт

20

09443-07025

Пружина

1 170 ₽/шт

21

54441-16B01

EXCENTRICO

22

09280-12012

КОЛЬЦО УПЛОТНИТЕЛЬНОЕ

391 ₽/шт

23

54484-16B00

Spring, cam lever return

24

09160-12011

Уплотнение

97 ₽/шт

25

54451-29C00

LEVER,FR BRAKE CAM

1 091 ₽/шт

26

09118-06086

Болт 6X25

1 680 ₽/шт

27

08310-00067

Гайка

81 ₽/шт

28

54310-16B00

TORQUELINK COMP.FRONT

29

54341-25E00

BUSH,TORQUELINK

255 ₽/шт

30

54342-16B00

COVER,TORQUELINK

31

09100-08280

BOLT(8X49)

1 880 ₽/шт

32

08319-2108A

Гайка

1 250 ₽/шт

33

09100-08223

BOLT(8X35)

8 600 ₽/шт

34

08319-31087

Гайка

178 ₽/шт
