16B - SPEEDOMETER (P09,E94)

16B - SPEEDOMETER (P09,E94)

Например: 34100-29C70

1

34100-29C70

Speedometer assy (kilo)

2

34111-29C70

.case, meter

3

34120-29C70

.meter, speed

4

34125-29C70

.panal, meter

5

34150-10B00

.hood, meter

6

34173-29C70

.socket

7

34383-10B00

.screw

8

09471-12028

Лампочка

210 ₽/шт

9

09471-12077

BULB(12V1.7W,T10,WB121)

1 990 ₽/шт

10

02112-7410B

SCREW

1 330 ₽/шт

11

34198-04750

Cap

12

09148-04020

NUT

1 410 ₽/шт

15

08322-0104B

Шайба

81 ₽/шт

16

34910-29C13
