24 - SPEEDOMETER - TACHOMETER

24 - SPEEDOMETER - TACHOMETER

Например: 34110-44230

1

34110-44230

Speedometer (kilo & mile)

1

34110-45300

2

34980-45020

KNOB

305 ₽/шт

3

34189-45300

Damper

4

34151-45300

Cover,speedomet

5

34210-47241

Tachdmeter

6

34189-45300

Damper

7

34251-45300

Cover,tachomete

8

36381-44200

Case, pilot box outer

9

34993-47000

Seal

10

36382-45301

Case, pilot box inner

11

36386-45300

Panel, pilot lens

12

36300-45811

Lens set, pilot

13

09471-12028

Лампочка

210 ₽/шт

13

36325-45302

14

34173-45302

Socket

14

09471-12028

Лампочка

210 ₽/шт

14

09471-06052-LCP

Bulb

15

09471-12001-LCP

Bulb 6v/1,7w

15

09471-12028

Лампочка

210 ₽/шт

16

36453-47200

Socket, gear indicator

17

09471-12071

BULB(14V1.12W)

3 440 ₽/шт

17

09471-12078

Bulb 12v,1.12w

18

36457-45100

Vis

19

34950-44200

Bracket

20

34193-45300

ORNAMENT,SPEEDOMETER

2 874 ₽/шт

21

34293-45300

ORNAMENT,TACHOMETER

2 874 ₽/шт

22

34191-45300

Cushion

23

08322-0105B

Шайба

81 ₽/шт

24

08313-1005A

Гайка

1 090 ₽/шт

25

36383-45300

Cover, pilot box

26

36384-45300

Cushion

27

36387-45300

Screw

28

09111-08031

Vis

29

09160-10035

Шайба

136 ₽/шт

30

34956-31001

CUSHION,METER BRACKET

501 ₽/шт

31

09160-08130

Шайба

102 ₽/шт

32

08321-01087

Пластина замка

81 ₽/шт

33

08313-10087

Гайка

1 330 ₽/шт

34

34910-31990

Câble de compteur de vitesse

34

34910-45115

Cable Assy,speedometer

2 502 ₽/шт

35

34938-45100

CLAMP,SPEEDOMETER CABLE

254 ₽/шт

36

01550-0616B

БОЛТ

81 ₽/шт

37

08322-0106A

Шайба

81 ₽/шт

38

34940-47034

Cable Assy,tachometer

3 995 ₽/шт

38

34940-05312

Cable Assy,tachometer

4 809 ₽/шт
