Transmission

Transmission
Например: T1180299
3
T1180299
Input Shaft Bearing Housing
4
T3800123
Bearing Ball, 25 x 62 x 17
5
T1180297
Bearing Retainer Plate
6
T1180296
Gearbox Shaft, Input & 1st, 13
7
T1180354
Bush, 28 x 31 x 11.2, Input 5t
8
T1180114
Gear, Input, 5th, 22T
9
T1180331
Washer, Splined, 28 x 34 x 1.5
5 шт. в узле
10
T3500058
Circlip, 28mm
5 шт. в узле
11
T1180115
Gear, Input, 3rd/4th, 24T/21T
12
T1180116
Gear, Input, 6th, 23T
13
T1180357
Collar, Splined, 18x11.5, Inpu
14
T1180347
Rondelle (Splined, 28mm)
2 шт. в узле
15
T1180348
Rondelle (Lock)
2 шт. в узле
16
T1180352
Gear, Input, 2nd, 21T
17
T1180334
Rondelle (Thrust, 20mm)
2 шт. в узле
18
T3205065
Bolt, HHF, Lghtd, M6 x 20, Enc
3 шт. в узле
19
T3800068
Bearing, Needle Roller, Dowel
20
T3000032
Dowel, Dia 6 x 10.8
21
T1180405
Gear, Output, 1st, 34T
22
T1180359
Bush, 22 x 25 x 11, Output 1st
23
T1180358
Rondelle (Thrust 22mm)
24
T1189251
Gear, Output, 5th, 25T
25
T1180124
Gear, Output, 4th, 27T
26
T1180368
Collar, Spline, 28 x 9, Output
2 шт. в узле
27
T1180123
Gear, Output, 3rd, 36T
28
T1180121
Gear, Output, 6th, 24T
29
T1180367
Bush, 28 x 31 x 8.4, Output, 2
30
T1180362
Gear, Output 2nd, 39T
31
T1180360
Shaft, Gearbox, Output
32
T3800094
Ring Bearing Retainer
33
T3800066
Bearing 6305, High Duty
34
T1180369
Spacer, Sprocket
35
T3600113
Seal, Oil 35 x 62 x 5
36
T1181620
Sprocket, Output, 16T
37
T1180328
Washer, Tab, Sprocket
38
T1180183
Nut, M20 x 1.5, 6 Deep
